DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
23
Chapter 3 802.1Q VLAN Command
List
create vlan <vlan_name 32> tag <vlanid 2-4094> {type [1q_vlan | private_vlan]} {advertisement}
create vlan vlanid <vidlist> {type [1q_vlan | private_vlan]} {advertisement}
delete vlan <vlan_name 32>
delete vlan vlanid <vidlist>
config vlan <vlan_name 32> {[add [tagged | untagged | forbidden] | delete] <portlist> |
advertisement [enable | disable]}(1)
config vlan vlanid <vidlist> {[add [tagged | untagged | forbidden] | delete] <portlist> |
advertisement [enable | disable] | name <vlan_name 32>}(1)
config port_vlan [<portlist> | all] {gvrp_state [enable | disable] | ingress_checking [enable |
disable] | acceptable_frame [tagged_only | admit_all] | pvid <vlanid 1-4094>}(1)
show vlan {<vlan_name 32>}
show vlan ports {<portlist>}
show vlan vlanid <vidlist>
show port_vlan {<portlist>}
enable pvid auto_assign
disable pvid auto_assign
show pvid auto_assign
config gvrp [timer {join < value 100-100000> | leave < value 100-100000> | leaveall <value 100-
100000>} | nni_bpdu_addr [dot1d | dot1ad]]
show gvrp
enable gvrp
disable gvrp
config private_vlan [<vlan_name 32> | vid <vlanid 2-4094>] [add [isolated | community] | remove]
[<vlan_name 32> | vlanid <vidlist>]
show private_vlan {[<vlan_name 32> | vlanid<vidlist>]}
create vlan 3-1
Description
This command is used to create a VLAN on the Switch. The VLAN ID must be always specified for
creating a VLAN.
Format
create vlan <vlan_name 32> tag <vlanid 2-4094> {type [1q_vlan | private_vlan]}
{advertisement}
Parameters
<vlan_name 32> - Enter the VLAN name to be created. The VLAN name can be up to 32
characters long.
tag - Creates the VLAN ID.
<vlanid 2-4094> - Enter the VLAN ID. The VLAN ID value must be between 2 and 4094.
type - (Optional) Specify the type of VLAN here.
1q_vlan - (Optional) Specify that the type of VLAN used is based on the 802.1Q standard.
