DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
543
enable mirror 51-2
Description
This command is used to enable mirror function without having to modify the mirror session
configuration.
Format
enable mirror
Parameters
None.
Restrictions
Only Administrators and Operators can issue this command.
Example
To enable mirroring function:
DGS-3000-26TC:admin#enable mirror
Command: enable mirror
Success.
DGS-3000-26TC:admin#
disable mirror 51-3
Description
This command is used to disable mirror function without having to modify the mirror session
configuration.
Format
disable mirror
Parameters
None.
Restrictions
Only Administrators and Operators can issue this command.
Example
To disable mirroring function:
