D-Link DGS-3000 User Manual

DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
701
Chapter 70 RADIUS Client Command
List
config radius add <server_index 1-3> [<server_ip> | <ipv6addr>] [key <password 32> |
encryption_key <password 56>] [default | {auth_port <udp_port_number 1-65535> | acct_port
<udp_port_number 1-65535> | timeout <sec 1-255> | retransmit <int 1-20>}(1)]
config radius delete <server_index 1-3>
config radius <server_index 1-3> {ipaddress [<server_ip> | <ipv6addr>] | [key <password 32> |
encryption_key <password 56 >] | auth_port [<udp_port_number 1-65535 >| default] | acct_port
[<udp_port_number 1-65535> | default ] | timeout [<sec 1-255> | default] | retransmit [<int 1-
20> | default]}(1)
show radius
show auth_client
show acct_client
config radius add 70-1
Description
This command is used to add a new RADIUS server. The server with lower index has higher
authenticative priority.
Format
config radius add <server_index 1-3> [<server_ip> | <ipv6addr>] [key <password 32> |
encryption_key <password 56>] [default | {auth_port <udp_port_number 1-65535> |
acct_port <udp_port_number 1-65535> | timeout <sec 1-255> | retransmit <int 1-20>}(1)]
Parameters
<server_index 1-3> - Enter the RADIUS server index. This value must be between 1 and 3.
<server_ip> - Enter the IP address of the RADIUS server here.
<ipv6addr> - Enter the IPv6 address of the RADIUS server here.
key - The key pre-negotiated between switch and the RADIUS server. It is used to encrypt user’s
authentication data before being transmitted over internet. The maximum length of the key is
32.
<password 32> - Enter the password here. The password can be up to 32 characters long.
encryption_key - Specify the key pre-negotiated between the switch and the RADIUS server. It
is used to encrypt the user’s authentication data before being transmitted over the Internet.
<password 56> - Enter the enryption key.
default - Sets the authentication UDP port number to 1812 accounting UDP port number to 1813,
timeout to 5 seconds and retransmit to 2.
auth_port - Specify the UDP port number which is used to transmit RADIUS authentication data
between the Switch and the RADIUS server. The range is 1 to 65535.
<udp_port_number 1-65535> - Enter the authentication port number here. This value must
be between 1 and 65535.
acct_port - Specify the UDP port number which is used to transmit RADIUS accounting statistics
between the Switch and the RADIUS server. The range is 1 to 65535.
<udp_port_number 1-65535> - Enter the accounting port number here. This value must be
between 1 and 65535.
timeout - The waiting time in second for the server to reply. The default value is 5 seconds.
<sec 1-255> - Enter the timeout value here. This value must be between 1 and 255 seconds.
