DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
189
Chapter 17 CPU Interface Filtering
Command List
create cpu access_profile profile_id <value 1-5> [ethernet {vlan | source_mac <macmask
000000000000-ffffffffffff> | destination_mac <macmask 000000000000-ffffffffffff> | 802.1p |
ethernet_type} | ip {vlan | source_ip_mask <netmask> | destination_ip_mask <netmask> | dscp
| [icmp {type | code} | igmp {type} | tcp {src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex
0x0-0xffff> | flag_mask [all | {urg | ack | psh | rst | syn | fin}]} | udp {src_port_mask <hex 0x0-
0xffff> | dst_port_mask <hex 0x0-0xffff>} | protocol_id_mask <hex 0x0-0xff> {user_define_mask
<hex 0x0-0xffffffff>}]} | packet_content_mask {offset_0-15 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>|offset_16-31 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>|offset_32-47 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>|offset_48-63 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>|offset_64-79 <hex 0x0-0xffffffff> <hex 0x0-
0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>} | ipv6 {class | flowlabel | source_ipv6_mask
<ipv6mask> | destination_ipv6_mask <ipv6mask>}]
delete cpu access_profile [profile_id <value 1-5> | all]
config cpu access_profile profile_id <value 1-5> [add access_id [auto_assign | <value 1-100>]
[ethernet {[vlan <vlan_name 32> | vlan_id <vlanid 1-4094>] | source_mac <macaddr> |
destination_mac <macaddr> | 802.1p <value 0-7> | ethernet_type <hex 0x0-0xffff>} | ip {[vlan
<vlan_name 32> | vlan_id <vlanid 1-4094>] | source_ip <ipaddr> | destination_ip <ipaddr> |
dscp <value 0-63> | [icmp {type <value 0-255> | code <value 0-255>} | igmp {type <value 0-
255>} | tcp {src_port <value 0-65535> | dst_port <value 0-65535> | flag [all | {urg | ack | psh | rst
| syn | fin}]} | udp {src_port <value 0-65535> | dst_port <value 0-65535>} | protocol_id <value 0-
255> {user_define <hex 0x0-0xffffffff>}]} | packet_content {offset_0-15 <hex 0x0-0xffffffff> <hex
0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_16-31 <hex 0x0-0xffffffff> <hex
0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_32-47 <hex 0x0-0xffffffff> <hex
0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_48-63 <hex 0x0-0xffffffff> <hex
0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_64-79 <hex 0x0-0xffffffff> <hex
0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>} | ipv6 {class <value 0-255> | flowlabel
<hex 0x0-0xfffff> | source_ipv6 <ipv6addr> | destination_ipv6 <ipv6addr>}] port [<portlist> | all]
[permit | deny] {time_range <range_name 32>} | delete access_id <value 1-100>]
enable cpu_interface_filtering
disable cpu_interface_filtering
show cpu access_profile {profile_id <value 1-5>}
create cpu access_profile 17-1
Description
This command is used to create CPU access list profiles.
Format
create cpu access_profile profile_id <value 1-5> [ethernet {vlan | source_mac <macmask
000000000000-ffffffffffff> | destination_mac <macmask 000000000000-ffffffffffff> | 802.1p |
ethernet_type} | ip {vlan | source_ip_mask <netmask> | destination_ip_mask <netmask> |
dscp | [icmp {type | code} | igmp {type} | tcp {src_port_mask <hex 0x0-0xffff> |
dst_port_mask <hex 0x0-0xffff> | flag_mask [all | {urg | ack | psh | rst | syn | fin}]} | udp
{src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex 0x0-0xffff>} | protocol_id_mask <hex
0x0-0xff> {user_define_mask <hex 0x0-0xffffffff>}]} | packet_content_mask {offset_0-15
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_16-31
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_32-47
