DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
190
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_48-63
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_64-79
<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>} | ipv6 {class |
flowlabel | source_ipv6_mask <ipv6mask> | destination_ipv6_mask <ipv6mask>}]
Parameters
profile_id - Specify the profile ID used here.
<value 1-5> - Enter the profile ID value here. This value must be between 1 and 5.
ethernet - Specify that the profile type will be Ethernet.
vlan - (Optional) Specify a VLAN mask.
source_mac - (Optional) Specify the source MAC mask.
<macmask> - Enter the source MAC mask here.
destination_mac - (Optional) Specify the destination mac mask.
<macmask> - Enter the destination MAC mask here.
802.1p - (Optional) Specify 802.1p priority tag mask.
ethernet_type - (Optional) Specify the ethernet type mask.
ip - Specify that the profile type will be IP.
vlan - (Optional) Specify a VLAN mask.
source_ip_mask - (Optional) Specify an IP source submask.
<netmask> - Enter the IP source submask here.
destination_ip_mask - (Optional) Specify an IP destination submask.
<netmask> - Enter the IP destination submask here.
dscp - (Optional) Specify the DSCP mask.
icmp - (Optional) Specify that the rule applies to ICMP traffic.
type - (Optional) Specify that the rule applies to ICMP type traffic.
code - (Optional) Specify that the rule applies to ICMP code traffic.
igmp - (Optional) Specify that the rule applies to IGMP traffic.
type - (Optional) Specify that the rule applies to IGMP type traffic.
tcp - Specify that the rule applies to TCP traffic.
src_port_mask - (Optional) Specify the TCP source port mask.
<hex 0x0-0xffff> - Enter the source TCP port mask here.
dst_port_mask - (Optional) Specify the TCP destination port mask.
<hex 0x0-0xffff> - Enter the destination TCP port mask here.
flag_mask - (Optional) Specify the TCP flag field mask.
all - Specify that the TCP flag field mask will be set to all.
urg - (Optional) Specify that the TCP flag field mask will be set to urg.
ack - (Optional) Specify that the TCP flag field mask will be set to ack.
psh - (Optional) Specify that the TCP flag field mask will be set to psh.
rst - (Optional) Specify that the TCP flag field mask will be set to rst.
syn - (Optional) Specify that the TCP flag field mask will be set to syn.
fin - (Optional) Specify that the TCP flag field mask will be set to fin.
udp - (Optional) Specify that the rule applies to UDP traffic.
src_port_mask - (Optional) Specify the UDP source port mask.
<hex 0x0-0xffff> - Enter the source UDP port mask here.
dst_port_mask - (Optional) Specify the UDP destination port mask.
<hex 0x0-0xffff> - Enter the destination UDP port mask here.
protocol_id_mask - (Optional) Specify that the rule applies to the IP protocol ID traffic.
<hex 0x0-0xff> - Enter the IP protocol ID mask here.
user_define_mask - (Optional) Specify that the rule applies to the IP protocol ID and the
mask options behind the first 4 bytes of the IP payload.
<hex 0x0-0xffffffff> - Enter the user-defined IP protocol ID mask here.
packet_content_mask - Specify the frame content mask, there are 5 offsets in maximum could
be configured. Each offset presents 16 bytes, the range of mask of frame is 80 bytes (5
offsets) in the first eighty bytes of frame.
offset_0-15 - (Optional) Specify that the mask pattern offset of the frame will be between 0
and 15.
<hex 0x0-0xffffffff> - Enter the mask pattern offset of the frame between 0 and 15 here.
offset_16-31 - (Optional) Specify that the mask pattern offset of the frame will be between 16
