D-Link DGS-3000 - Chapter 6 Access Control List (ACL) Command List

DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
87
Chapter 6 Access Control List (ACL)
Command List
create access_profile profile_id <value 1-512> {profile_name <name 32>} [ethernet {vlan {<hex
0x0-0x0fff>} | source_mac <macmask 000000000000-ffffffffffff> | destination_mac <macmask
000000000000-ffffffffffff> | 802.1p | ethernet_type} | ip {vlan {<hex 0x0-0x0fff>} |
source_ip_mask <netmask> | destination_ip_mask <netmask> | dscp | [icmp {type | code } |
igmp {type } | tcp {src_port_mask <hex0x0-0xffff> | dst_port_mask <hex 0x0-0xffff> | flag_mask
[all | {urg | ack | psh | rst | syn | fin}]} | udp {src_port_mask <hex 0x0-0xffff> | dst_port_mask
<hex 0x0-0xffff>} | protocol_id_mask <hex 0x0-0xff> {user_define_mask <hex 0x0-0xffffffff>}]} |
packet_content_mask { offset_chunk_1 <value 0-31> <hex 0x0-0xffffffff> | offset_chunk_2
<value 0-31> <hex 0x0-0xffffffff> | offset_chunk_3 <value 0-31> <hex 0x0-0xffffffff> |
offset_chunk_4 <value 0-31> <hex 0x0-0xffffffff>} | ipv6 {class | flowlabel | source_ipv6_mask
<ipv6mask> | destination_ipv6_mask <ipv6mask> | [tcp {src_port_mask <hex 0x0-0xffff> |
dst_port_mask <hex 0x0-0xffff>} | udp { src_port_mask <hex 0x0-0xffff> | dst_port_mask <hex
0x0-0xffff>} | icmp {type | code }]}]
delete access_profile [profile_id <value 1-512> | profile_name <name 32> |all]
config access_profile [profile_id <value 1-512> | profile_name <name 32>] [add access_id
[auto_assign | <value 1-256>][ethernet {[vlan <vlan_name 32> | vlan_id <vlanid 1-4094>] {mask
<hex 0x0-0x0fff>} | source_mac <macaddr> {mask <macmask>} | destination_mac <macaddr>
{mask <macmask>} | 802.1p <value 0-7> | ethernet_type <hex 0x0-0xffff>} | ip {[vlan
<vlan_name 32> | vlan_id <vlanid 1-4094>] {mask <hex 0x0-0x0fff>} | source_ip <ipaddr>
{mask <netmask>} | destination_ip <ipaddr> {mask <netmask>} | dscp <value 0-63> | [icmp
{type <value 0-255> | code <value 0-255>} | igmp {type <value 0-255>} | tcp {src_port <value 0-
65535> {mask <hex 0x0-0xffff>} | dst_port <value 0-65535> {mask <hex 0x0-0xffff>} | flag [all |
{urg | ack | psh | rst | syn | fin}]} | udp {src_port <value 0-65535> {mask <hex 0x0-0xffff>} |
dst_port <value 0-65535> {mask <hex 0x0-0xffff>}} | protocol_id <value 0-255> {user_define
<hex 0x0-0xffffffff> {mask <hex 0x0-0xffffffff>}}]} | packet_content {offset_chunk_1 <hex 0x0-
0xffffffff> {mask <hex 0x0-0xffffffff>} | offset_chunk_2 <hex 0x0-0xffffffff> {mask <hex 0x0-
0xffffffff>} | offset_chunk_3 <hex 0x0-0xffffffff> {mask <hex 0x0-0xffffffff>} | offset_chunk_4
<hex 0x0-0xffffffff> {mask <hex 0x0-0xffffffff>}} | ipv6 {class <value 0-255> | flowlabel <hex 0x0-
0xfffff> | source_ipv6 <ipv6addr> {mask<ipv6mask>} | destination_ipv6 <ipv6addr> {mask
<ipv6mask>} | [tcp {src_port<value 0-65535> {mask <hex 0x0-0xffff>} | dst_port <value 0-
65535> {mask <hex0x0-0xffff>}} | udp {src_port <value 0-65535> {mask <hex 0x0-0xffff>} |
dst_port <value 0-65535> {mask <hex 0x0-0xffff>}} | icmp {type<value 0-255> | code <value 0-
255>}]}] [port [<portlist> | all] | vlan_based [vlan <vlan_name 32> | vlan_id <vlanid 1-4094>]]
[permit {priority <value 0-7> {replace_priority} | [replace_dscp_with <value 0-63> |
replace_tos_precedence_with <value 0-7>] | counter[enable | disable]} | mirror | deny]
{time_range <range_name 32>} | delete access_id <value 1-256>]
show access_profile {[profile_id <value 1-512> | profile_name <name 32>]}
config flow_meter [profile_id <value 1-512> | profile_name <name 32>] access_id <value 1-256>
[rate [<value 1-1048576>] {burst_size [<value 1-262144>]} rate_exceed [drop_packet |
remark_dscp <value 0-63>] | tr_tcm cir <value 1-1048576> {cbs <value 1-262144>} pir <value
1-1048576> {pbs <value 1-262144>} {[color_blind | color_aware]} {conform [permit |
replace_dscp <value 0-63>] {counter [enable | disable]}} exceed [permit {replace_dscp <value
0-63>} | drop] {counter [enable | disable]} violate [permit {replace_dscp <value 0-63>} | drop]
{counter [enable |disable]} | sr_tcm cir <value 1-1048576> cbs <value 1-262144> ebs <value 1-
262144> {[color_blind | color_aware]} {conform [permit | replace_dscp <value 0-63>] {counter
[enable | disable]}} exceed [permit {replace_dscp <value 0-63>} | drop] {counter [enable |
disable]} violate [permit {replace_dscp <value 0-63>} | drop] {counter [enable | disable]} |
delete]
show flow_meter {[profile_id <value 1-512> | profile_name <name 32>] {access_id <value 1-
256>}}
config time_range <range_name 32> [hours start_time <time hh:mm:ss> end_time <time
hh:mm:ss> weekdays <daylist> | delete]
