DGS-3000 Series Layer 2 Managed Gigabit Ethernet Switch CLI Reference Guide
92
0x0-0xffff>} | flag [all | {urg | ack | psh | rst | syn | fin}]} | udp {src_port <value 0-65535>
{mask <hex 0x0-0xffff>} | dst_port <value 0-65535> {mask <hex 0x0-0xffff>}} | protocol_id
<value 0-255> {user_define <hex 0x0-0xffffffff> {mask <hex 0x0-0xffffffff>}}]} |
packet_content {offset_chunk_1 <hex 0x0-0xffffffff> {mask <hex 0x0-0xffffffff>} |
offset_chunk_2 <hex 0x0-0xffffffff> {mask <hex 0x0-0xffffffff>} | offset_chunk_3 <hex 0x0-
0xffffffff> {mask <hex 0x0-0xffffffff>} | offset_chunk_4 <hex 0x0-0xffffffff> {mask <hex 0x0-
0xffffffff>}} | ipv6 {class <value 0-255> | flowlabel <hex 0x0-0xfffff> | source_ipv6 <ipv6addr>
{mask<ipv6mask>} | destination_ipv6 <ipv6addr> {mask <ipv6mask>} | [tcp {src_port<value
0-65535> {mask <hex 0x0-0xffff>} | dst_port <value 0-65535> {mask <hex0x0-0xffff>}} | udp
{src_port <value 0-65535> {mask <hex 0x0-0xffff>} | dst_port <value 0-65535> {mask <hex
0x0-0xffff>}} | icmp {type<value 0-255> | code <value 0-255>}]}] [port [<portlist> | all] |
vlan_based [vlan <vlan_name 32> | vlan_id <vlanid 1-4094>]] [permit {priority <value 0-7>
{replace_priority} | [replace_dscp_with <value 0-63> | replace_tos_precedence_with <value
0-7>] | counter[enable | disable]} | mirror | deny] {time_range <range_name 32>} | delete
access_id <value 1-256>]
Parameters
profile_id - Specify the index of the access list profile.
<value 1-512> - Enter the profile ID value here. This value must be between 1 and 512.
profile_name - Specify the name of the profile.
<name 32> - Enter the profile name here. This name can be up to 32 characters long.
add - Specify that a profile or a rule will be added.
access_id - Specify the index of the access list entry. The value range is 1-256, but the
supported maximum number of entries depends on the project. If the auto_assign option is
selected, the access ID is automatically assigned, when adding multiple ports.
auto_assign - Specify that the access ID will automatically be assigned.
<value 1-256> - Enter the access ID used here. This value must be between 1 and 256.
ethernet - Specify to configure the ethernet access profile.
vlan - (Optional) Specify the VLAN name.
<vlan_name 32> - Enter the name of the VLAN here. This name can be up to 32
characters long.
vlan_id - (Optional) Specify the VLAN ID used.
<vlanid 1-4094> - Enter the VLAN ID used here. This value must be between 1 and 4094.
mask - (Optional) Specify an additional mask parameter that can be configured.
<hex 0x0-0x0fff> - Enter the mask value here.
source_mac - (Optional) Specify the source MAC address.
<macaddr> - Enter the source MAC address used for this configuration here.
mask - (Optional) Specify an additional mask parameter that can be configured.
<macmask> - Enter the source MAC mask used here.
destination_mac - (Optional) Specify the destination MAC address.
<macaddr> - Enter the destination MAC address used for this configuration here.
mask - (Optional) Specify an additional mask parameter that can be configured.
<macmask> - Enter the destination MAC mask here.
802.1p - (Optional) Specify the value of the 802.1p priority tag.
<value 0-7> - Enter the 802.1p priority tag value. The priority tag ranges from 1 to 7.
ethernet_type - (Optional) Specify the Ethernet type.
<hex 0x0-0xffff> - Enter the Ethernet type mask here.
ip - Specify to configure the IP access profile.
vlan - (Optional) Specify a VLAN name.
<vlan_name 32> - Enter the name of the VLAN here. This name can be up to 32
characters long.
vlan_id - (Optional) Specify that VLAN ID used.
<vlanid 1-4094> - Enter the VLAN ID used here. This value must be between 1 and 4094.
mask – (Optional) Specify an additional mask parameter that can be configured.
<hex 0x0-0x0fff> - Enter the mask value here.
source_ip - (Optional) Specify an IP source address.
<ipaddr> - Enter the source IP address used for this configuration here.
mask - (Optional) Specify an additional mask parameter that can be configured.
