SV-EMS-220/221 Installation and Configuration
7-24 SkyView System Installation Guide - Revision AA
36
Blue or Unwired
No connection
37
Green or Unwired
No connection
Table 35 – Suggested Lycoming/Continental 4-cylinder Fuel Injected Sensor Connections
for EMS D37F Harness
Pin
EMS D25M Thermocouple
Harness Wire Color
Sensor
(with Dynon Avionics P/N if applicable)
1
No Wire
No connection
2
No Wire
No connection
3
No Wire
No connection
4
No Wire
No connection
5
No Wire
No connection
6
Red
CHT 4 (J-type thermocouple, 100404-000)
7
Red
EGT 4 (K-type thermocouple, 100405-000)
8
Red
CHT 3 (J-type thermocouple, 100404-000)
9
Red
EGT 3 (K-type thermocouple, 100405-000)
10
Red
CHT 2 (J-type thermocouple, 100404-000)
11
Red
EGT 2 (K-type thermocouple, 100405-000)
12
Red
CHT 1 (J-type thermocouple, 100404-000)
13
Red
EGT 1 (K-type thermocouple, 100405-000)
14
No Wire
No connection
15
No Wire
No connection
16
No Wire
No connection
17
No Wire
No connection
18
White
CHT 4 (J-type thermocouple, 100404-000)
19
Yellow
EGT 4 (K-type thermocouple, 100405-000)
20
White
CHT 3 (J-type thermocouple, 100404-000)
21
Yellow
EGT 3 (K-type thermocouple, 100405-000)
22
White
CHT 2 (J-type thermocouple, 100404-000)
23
Yellow
EGT 2 (K-type thermocouple, 100405-000)
24
White
CHT 1 (J-type thermocouple, 100404-000)
25
Yellow
EGT 1 (K-type thermocouple, 100405-000)
Table 36 – Suggested Lycoming/Continental 4-cylinder Fuel Injected Sensor Connections
for D25M Harness
