Appendix B: Specifications
22-8 SkyView System Installation Guide - Revision AA
Audio frequency conducted
susceptibility
18.0
Equipment tested to Category B
Induced signal susceptibility
19.0
Equipment tested to Category AC
Radio frequency susceptibility
20.0
Equipment tested to Category TT
Radio frequency emission
21.0
Equipment tested to Category B
Lightning induced transient
susceptibility
22.0
Equipment identified as Category XXXX – no test required
Lightning direct effects
23.0
Equipment identified as Category X – no test required
Icing
24.0
Equipment identified as Category X – no test required
Electrostatic Discharge
25.0
Equipment identified as Category X – no test required
Fire, Flammability
26.0
Equipment identified as Category C
Table 104 – SV-XPNDR-261/262 Qualification Forms
SV-XPNDR-261/262 ADS-B Information
SV-XPNDR-261/262 transponder modules include support for Extended Squitter ADS-B out. The
SV-XPNDR-261/262 with SV-XPNDR Software 2.02 or higher is a DO-260B compliant broadcast
participant.
ADS-B Parameters Supported
The following table lists the ADS-B parameters that are transmitted by the SV-XPNDR-261/262
transponder when connected to an appropriate GPS receiver.
Parameter
BDS Register
SPI
0,5
Emergency Indicator
0,5
Barometric Altitude
0,5
Quality Indicator (NIC)
0,5
Airborne
Position
Latitude
0,5
Longitude
0,5
Quality Indicator (NIC)
0,6
Surface
Position
Latitude
0,6
Longitude
0,6
Surface Ground Speed
0,6
Surface Ground Track
0,6
Aircraft Identification
0,8
Airborne Ground Velocity
0,9
Geometric to Barometric
altitude difference
0,9
Geometric Vertical Rate
0,9
Squawk Code
6,1
Emergency Status
6,1
Quality Indicator (NACp)
6,5
Quality Indicator (NACv)
6,5
Quality Indicator (SIL)
6,5
Version Indicator
6,5
