Appendix B: Specifications
22-10 SkyView System Installation Guide - Revision AA
SV-COM-C25 Technical Specifications
Specification
Characteristics
Current Requirement
RX: 200 mA / TX: 3.0A
FCC Identification
WU6-310001-000
Voltage Input
10 V to 30 V DC
Temperature Range
-20° C to +60° C (-4° F to +140° F)
Audio
Microphone
150 Ohms nominal input
impedance
70 mV RMS for 70% modulation
Maximum input 2.0V P-P
Headphone
150 Ohms nominal output
impedance
150 mW output power into 150
Ohms
Short Circuit Protected
Transmitter
Antenna Requirements
50 Ohms impendence
BNC connector
VSWR < 2.5:1
Audio Distortion
< 10 %
Audio Frequency Response
200 to 3.0 kHz
Carrier Noise Level
> 35 dB down
Class
4
Duty Cycle
20 %
Frequency Range
118.000 – 136.975 MHz
Frequency Tolerance
+/- 5 PPM from -20 °C to +60 °C
Modulation Capability
85 % Maximum
Modulation
A3E
Output Power
6W minimum (10V DC)
Sidetone Level
Up to 150 mW into 150 Ohms
Stuck Microphone Timeout
31 to 34 Seconds
Receiver
Audio Frequency Response
150 to 3.0 kHz
Channel Size
25 kHz
Class
D
Frequency Range
118.000 – 136.975 MHz
Frequency Tolerance
+/- 5 PPM from -20 °C to +60 °C
Selectivity
> 60 dB@ +/- 25 kHz
Sensitivity
-111 dBm @ 12 dB
Squelch
Automatic, -1 µV setpoint
Table 106 – SV-COM-C25 Specifications
