Appendix B: Specifications
SkyView System Installation Guide - Revision AA 22-13
Specification
Parameters
Update Rate
5 Hz
Receives WAAS Correction Signals
(where available)
Yes
Uses all available positioning satellites?
Yes
Time to Acquire Fix (cold start)
60 seconds
Data Interface
TX – Grey/Violet
RS-232C @ 38,400 baud
RX – Grey/Orange
RS-232C (not currently implemented)
NMEA data sentences
GGA, GSA, GSV, RMC, VTG
Transponder Compatibility
Dynon Avionics SV-XPNDR-261
(minimum Software SW02.08 for
SIL/SDA=1)
System Compatibility
Dynon Avionics SkyView system;
minimum Software for SIL/SDA=1: v14.0
Advanced Flight Systems AF-5000 system
minimum Software for SIL/SDA=1:
v12.06.01
Maximum Altitude
60,000 feet (18,000 meters)
Maximum Velocity
1000 knots (1852 KPH)
Size
2.19 in. W x 0.75 in. H x 3.44 in. D
(55.63mm W x 19.05mm H x 87.38mm D)
Weight
7 oz. (198g)
Power Requirements
8V, 0.1A (Orange Wire +)
Electrical Ground (Black Wire -)
Operating Temperature
-4°F to +158°F (-20°C to +70°C)
Storage Temperature
-40°F to +140°F (-40°C to +60°C)
Table 109 – SV-GPS-250 Specifications
SV-GPS-2020 Specifications
Specification
Parameters
Description
WAAS GPS Receiver / Antenna
Compliance
Meets 14 CFR § 91.225, 14 CFR § 91.227,
and performance requirements of TSO-
c166b
Source Integrity Level (SIL)
3
System Design Assurance (SDA)
2
Update Rate
4 Hz
Receives WAAS Correction Signals
(where available)
Yes
