Appendix B: Specifications
SkyView System Installation Guide - Revision AA 22-5
Operating
Temperature
-20°C to +70°C
Transmitter Frequency
1090MHz ± 1MHz
Transmitter Power
250 Watts nominal; 125 Watts minimum at
antenna after allowing for 0.5dB connector
losses and 1.5dB cable losses.
Transmitter
Modulation
6M75 V1D
Receiver Frequency
1030 MHz
Receiver Sensitivity
-74Dbm ± 3Db
Physical Specifications (in the mounting tray)
Height
48mm (1.9”)
Width
66mm (2.5”)
Length
160mm (6.3”)
Weight
0.77lbs. (350 g)
Table 102 – SV-XPNDR-261 Specifications
SV-XPNDR-262 Specifications
Specification
Characteristics
Compliance
ETSO 2C112b Class 2 Level 2els (see below),
ETSO C166a Class B0, TSO C112c Class 2 Level
2els (see below), TSO C166b Class B0
Level 2 (Comm B) Level 1 + receive and
transmit 112 Bit Messages Level 2A Same as
Level 2 without the support air-initiated Comm
B messages
e – Extended squitter, the ability to send ADS-
B/1090ES data. This requires an external GPS
(certified GPS units only). Mode S
transponders with 1090ES capability can
always send ADS-B data out but may not be
able to receive ADS-B data in to receive traffic
information. The actual data out and data-in
capabilities for each model are shown out in
the table above.
l – Elementary surveillance, i.e. basic position
reporting derived from SSR radar, enhanced in
the case of a Mode S environment with higher
resolution (25') pressure altitude, unique ICAO
aircraft ID and other Mode S capabilities. Note
that this is different than 1090ES/ADS-B data-
out capabilities.
