SkyView System Installation Guide - Revision AA 27-1
27. Appendix G: Kavlico Pressure Sensor Part Numbers
Dynon Avionics Technical Advisory 120214 – Kavlico Pressure Sensors
Prior to installing Kavlico sensors, reference Dynon Avionics Technical
Advisory 120214 – Kavlico Pressure Sensors –
http://dynonavionics.com/docs/support_bulletins.html for
important information.
Kavlico pressure sensors sold by Dynon Avionics for fuel and oil pressure monitoring are
externally physically identical and can be distinguished only by the Kavlico P/N stamped on the
side. There are two lines of text stamped on one of the six faces. Example:
B2312 or K1013
P4055-15G or P4055-5025-1
The first line is the date code: month, day of month, two-digit year (20xx).
Month: A = January, B = February, C = March, D = April, E = May, F = June, G = July, H = August,
J = September, K = October, L = November, M = December
In the example above, B2312 = February 23, 2012, K1213 = October 12, 2013
The second line is the manufacturer (Kavlico) P/N.
11
Break in sequence – P4055-5025-5 is 100 PSI sensor, not stocked / sold by Dynon Avionics.
Dynon Avionics P/N
Usage
PSI
Stamped Kavlico P/N
Prior to 2014-07-01
After 2014-07-01
101715-000
Fuel Pressure
5
P4055-5G
P4055-5025
101690-000
Fuel Pressure
15
P4055-15G
P4055-5025-1
101691-000
Fuel Pressure
30
P4055-30G
P4055-P5025-2
101716-000
Fuel Pressure
50
P4055-50G
P4055-P5025-3
101692-000
Fuel Pressure
75
P4055-75G
P4055-P5025-4
101693-000
Oil Pressure
150
P4055-150G
P4055-P5025-6
11
Table 129 – Kavlico Sensor P/Ns
