Major Unit Physical Specifications
Table 5 contains physical specifications of major units. Note that dimensions listed in this table
are approximate—see the installation sections of each unit for installation drawings with
precise dimensions.
For physical specifications of minor units such as sensors, see Appendix B: Specifications, Table
99 – SkyView Minor Equipment Weights.
Unit
Dimensions
Weight
SV32
2.47” W x 4.20” H x 3.98” D
(63mm W x 107mm H x 101mm D)
2.00 lb. (0.90 kg)
SV42
2.47” W x 5.13” H x 3.98” D
(63mm W x 130mm H x 101mm D)
3.00 lb. (1.40 kg)
SV52
2.47” W x 6.05” H x 3.98” D
(63mm W x 154mm H x 101mm D)
4.00 lb. (1.80 kg)
SV-ADAHRS-200/201
4.71” W x 1.22” H x 2.61” D
(120mm W x 31mm H x 66mm D)
0.50 lb. (0.20 kg)
SV-ADSB-470
7.00” W x 1.19” H x 4.63” D
(177.8mm W x 30.1mm H x 117.6 D)
0.80 lb. (0.36 kg)
SV-AP-PANEL
3.53” x 1.80” x 1.27” D
(89.7mm x 45.7mm H x 32.4mm D)
0.30 lb. (0.15 kg)
SV-ARINC-429
4.75” W x 1.09” H x 2.61” D
(121mm W x 28mm H x 66mm D)
0.40 lb. (0.18 kg)
SV-BAT-320
3.30” W x 2.10” H x 3.90” D
(84mm W x 53mm H x 99mm D)
0.80 lb. (0.40 kg)
SV-COM-425
7.34” x 2.38” x 1.51”
(186.6mm x 60.45mm x 38.23mm)
0.75 lb. (0.34 kg)
SV-COM-PANEL
3.53” x 1.80” x 1.27” D
(89.7mm x 45.7mm H x 32.4mm D)
0.38 lb. (0.17 kg)
SV-COM-T8
(w/mounting tray)
2.5” W x 1.9”H x 6.3” D
(66mm W x 48mm H x 160mm D)
0.77 lb. (0.35 kg)
SV-D600/D700
7.64” W x 5.51” H x 2.14” D
(194mm W x 140mm H x 54mm D)
2.40 lb. (1.10 kg)
SV-D1000
(through S/N 8082)
10.32” W x 7.06” H x 2.14” D
(262mm W x 179mm H x 54mm D)
3.00 lb. (1.40 kg)
SV-D900
SV-D1000 (S/N 8083+)
SV-D1000T
10.32” W x 7.06” H x 2.33” D
(262mm W x 179mm H x 59mm D)
3.30 lb. (1.50 kg)
SV-EMS-220/221
6.35” W x 1.09” H x 2.99” D
(161mm W x 28mm H x 76mm D)
0.63 lb. (0.29 kg)
SV-GPS-250
2.19” W x 0.75” H x 3.44” D
(56mm W x 19mm H x 87mm D)
0.44 lb. (0.20 kg)
SV-GPS-2020
0.47 lb. (0.21 kg)
SV-HDX800
7.64” W 5.59” H x 3.21” D
(194mm W x 142mm H x 82mm D)
2.75 lb. (2.25 kg)
