Table 4 contains power specifications for SkyView units that are powered from aircraft power (not
powered by SkyView Network). The circuit protection recommendations are suitable for most
installations and assume that you are using Dynon Avionics harnesses and/or are following the
wiring advice in this Installation Guide. It may be possible to use different sized circuit protection if
the protective device has suitable load overhead for the device(s) connected to it. It is important
that circuit protection devices be appropriately sized to protect the wiring connected to them. 5A
circuit protection is recommend in most cases because that is the smallest circuit breaker that is
commonly available in certified versions, and Dynon Avionics wiring harnesses specify wire of at
least 22 AWG.
Unit
Current
requirement
@ 12V DC
Current
requirement
@ 24V DC
Circuit
Protection
Recommendation
SV-ADSB-470
0.20A
0.10A
5A
SV-AP-PANEL
(Trim motor control section)
Actual current
requirement
dependent on the trim
motor chosen
Not Applicable
12V only
5A
SV-COM-C25 - Receive
0.20A
0.10A
5A
SV-COM-C25 – Transmit
3.00A
1.50A
SV-COM-X83 – Receive
0.20A*
0.20A*
5A
SV-COM-X83 – Transmit
2.00A*
2.00A*
SV-INTERCOM-2S
0.10A*
0.10A*
5A
(Or add to another circuit)
SV-XPNDR-261/262
0.40A
0.20A
5A
Servos (All) – Not Engaged
0.13A
0.07A
5A
SV32 (all variants)
Moving @ 100% torque
1.30A
0.70A
SV42 (all variants)
Moving @ 100% torque
2.00A
1.00A
SV52 (all variants)
Moving @ 100% torque
2.80A
1.40A
Heated AOA / Pitot Probe
@ Maximum Heat
10.00A
Not Applicable
12V only
10A
Serial to Gray Code Converter
Module
0.01A*
0.01A*
5A
(or add to another circuit)
* Same current @12V and @24V – does not incorporate a switching power supply.
Table 4 – Power Specifications for SkyView Units Powered by Aircraft Power
