Dynon Avionics SkyView Classic - Fuel Flow Transducer

SV-EMS-220/221 Installation and Configuration
SkyView System Installation Guide - Revision AA 7-57
Configure the pin you chose: (SETUP MENU > EMS SETUP > SENSOR INPUT MAPPING > C37 P8 /
P22 / P23 / P31: Rotax 914 Diff Fuel Press
Fuel Flow Transducer
The approximate pulses/gallon setting for the FloScan 201B (i.e., cast metal case
legacy Dynon Avionics fuel flow transducer) is 28,000 to 31,000 (see the tag on the
unit). The approximate pulses/gallon for the Electronics International FT-60 Fuel
Flow Transducer (i.e., the red cube) is 68,000. You must configure the fuel flow
transducer using this numerical value in the Sensor Setup Menu (SETUP MENU >
HARDWARE CALIBRATION > EMS CALIBRATION > FUEL FLOW CALIBRATION). More
information on this topic is discussed in the Fuel Computer Configuration section of
this section.
FloScan 201B sensor only: make note of the numbers on the tag (pulses / gallon)
attached to the fuel flow sensor.
Dynon Avionics supplies the Electronics International FT-60 (Dynon Avionics P/N 100403-003)
fuel flow transducer. Although Dynon Avionics no longer supplies the FloScan 201B fuel flow
transducer, it remains supported as a sensor in SkyView.
FT-60
(P/N 100403-003
Fuel Flow Transducer
Wire Color
EMS Harness
Wire Color
EMS Harness Pin
Number
Function
Black
Black
Any of Pins 3, 13, 16,
17, or 30
Ground; this
Ground can be
shared with other
sensors
Yellow or White
Yellow
14
Fuel Flow Input 1
(From fuel tank)
Red
Red
It is acceptable to
share this pin / wire
with other sensors;
see Table 32 above.
15
It is acceptable to
share this pin / wire
with other sensors;
see Table 32 above.
+12 Volt
Auxiliary
Yellow or White
White / Black
19
Fuel Flow Input 2
for optional 2
nd
transducer
(Return to fuel
tank)
Table 58 - Fuel Flow Transducer Connections
Table 59
