Note that on SkyView SE, installation of the SV-BUTTON-LEVEL is the only method
that can be used to engage the AP LEVEL mode.
To provide a prominent LEVEL button on the panel, Dynon
Avionics offers the SV-BUTTON-LEVEL; P/N 102553-000 – see
Figure 170 for the SV-BUTTON-LEVEL kit, AND Figure 169 for
the SV-BUTTON-LEVEL button. Like most other Dynon
Avionics panel units, the SV-BUTTON-LEVEL is backlit and the
degree of backlighting is controlled by SkyView. The SV-
BUTTON-LEVEL is the same width, and similar appearance, as
Dynon Avionics panel units such as SV-AP-PANEL, SV-COM-
PANEL, SV-KNOB-PANEL, and SV-INTERCOM-2S.
Pressing an External LEVEL Button such as the SV-BUTTON-
LEVEL, the SkyView’s AP LEVEL mode is engaged.
In SkyView, this is equivalent to pressing MAIN MENU >
AUTOPILOT > LEVEL and the LEVEL button on the (optional) SV-
AP-PANEL.
