Appendix C: Wiring and Electrical Connections
23-8 SkyView System Installation Guide - Revision AA
SkyView Display
D37M Pin
SV-HARNESS-D37 Wire Color
Description
14
Orange with Yellow stripe
Contact Input 3
15
Orange with Green stripe
Contact Input 4
16
Red
USB Power
17
Black
USB Ground
18
White
USB-
19
Green
USB+
20
Red
Power Input
21
Black
Ground
22
Black
Ground
23
Black
Ground
24
Black
Ground
25
Violet
Dim Input
26
White
Dim Output
27
Orange with Red stripe
Contact Input 2
(Optional) External
GO AROUND Button
28
Orange with Black stripe
Contact Input 1
(Optional) External LEVEL Button
29
Orange
SV-GPS-250/2020 Power Output
30
Black
Audio Ground
31
Gray
Audio Output Right
32
Do Not Connect
Do Not Connect
33
Do Not Connect
Do Not Connect
34
Do Not Connect
Do Not Connect
35
Do Not Connect
Do Not Connect
36
Do Not Connect
Do Not Connect
37
Do Not Connect
Do Not Connect
Table 114 – SkyView Display D37M Pinout with Harness Wire Colors
SkyView D37M Block Diagram
Figure 217 illustrates basic SkyView display D37 electrical connections.
