Appendix C: Wiring and Electrical Connections
23-4 SkyView System Installation Guide - Revision AA
Connector: Molex Micro-Fit P/N 43640-0301 (Digi-Key P/N WM1856-ND)
Pins: Molex Micro-Fit P/N 43031-0007 (Digi-Key P/N WM1841-ND)
Wire: 22 AWG Tefzel, NO MORE THAN 24” LONG; Red w/Yellow stripe: M22759/16-
22-24; Black: M22759/16-22-0
Table 112 – SV-HARNESS-D37 wiring for SV-BAT-320 Connection Wiring
Do not cut off the connector supplied on the SV-BAT-320; instead, assemble a mating
connector as specified above.
OAT Connection
For SkyView pilots that are converting from other Dynon Avionics products, you can use your
installed OAT with the addition of the connector below. Both 100433-000 and 100433-001 are
compatible. The OAT wiring can be extended as required. If you have 100433-001, ignore the
red wire and connect the yellow and blue wires to the connector below. The OAT is non-
polarized; either wire can connect to either pin.
Connector: Molex Micro-Fit P/N 43645-0200 (Digi-Key P/N WM1845-ND)
Pins: Molex Micro-Fit P/N 43030-0007 (Digi-Key P/N WM1837-ND)
Wire: 22 AWG Tefzel
SkyView Equipment Electrical Connections
SkyView and SkyView SE displays have six connectors on the back of the unit as illustrated in
Figure 212:
One D37M for connection to the SkyView Display Harness (SV-HARNESS-D37)
Two D9M SkyView network connectors (SV-NET-xxxx)
Two Standard 4-pin USB 2.0 jacks for use with USB Series A plugs. Note that there is also a
USB port on the SV-HARNESS-D37 for convenience.
One standard 8-pin RJ45 connector for use with twisted pair category 5 Ethernet cable
