Appendix C: Wiring and Electrical Connections
SkyView System Installation Guide - Revision AA 23-3
Pair #3:
9-Pin Connector
Pin #
Wire Color
(SkyView Convention)
Signal Name
2
Black
Ground 1
7
Red
Power 1
Pair #4:
9-Pin Connector
Pin #
Wire Color
(SkyView Convention)
Signal Name
3
White/Black
Ground 2
9
White/Red
Power 2
Individual wire, not twisted with any other wire:
9-Pin Connector
Pin #
Wire Color
(SkyView Convention)
Signal Name
5
Orange
EMS Aux
This wire is currently used only for SV-EMS-220/221 modules, but future modules may also
require this signal, so we recommend it be included if you are building your own SkyView
Network cables.
Heat Shrink Bundling and Strain Relief
All wires should be bundled together with heat shrink and then strain relieved when exiting the
connector shell or hood.
USB Cable (from D37 connector)
The USB cable used in the SV-HARNESS-D37 is a unique part made to Dynon Avionics’
specifications for this application and is not sold separately. Attempting to terminate a typical
USB cable to a “DSUB” connector causes the USB device to perform marginally (in our
experience). For that reason, we recommend that a non-Dynon Avionics version of the SV-
HARNESS-D37 to not include a USB cable. Instead, purchase USB extension cables to plug into
the two USB ports on the back of the SkyView display.
SV-BAT-320 Connection
For warranty replacement, an SV-BAT-320 that is received at Dynon Avionics with
a different connector than the factory-installed connector is not be eligible for
warranty replacement.
To connect a harness (equivalent to SV-HARNESS-D37) not manufactured by Dynon Avionics
to an SV-BAT-320, the following specifications must be followed closely for the SV-BAT-320 to
charge and work correctly:
