 Configure the SkyView display serial port:
SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP > SERIAL PORT x SETUP
SERIAL IN DEVICE: (don’t care, does not affect ELT)
SERIAL IN/OUT BAUD RATE: (set to match speed of ELT; typically 4800 or 9600)
SERIAL OUT DEVICE: NMEA OUT (BASIC)
Dynon Avionics ADAHRS / EMS / SYSTEM / NMEA (GPS) Data Outputs
To output real-time data to an external serial device, such as a serial data logger or other device
that accepts NMEA or Dynon Avionics formats:
 Wire a serial transmit line from one display to the receive line on the external serial device.
If you have more than one SkyView display, make the same connection to all SkyView
displays.
 Ensure there is a shared ground between the SkyView display and the external serial device.
If you have more than one SkyView display, make the same connection to all SkyView
displays.
 Configure the serial port on the display appropriately under SETUP MENU > SYSTEM SETUP
> SERIAL PORT SETUP, SERIAL PORT x SETUP > selecting the desired output data format.
TIS Format Traffic Output
SkyView can be configured to output TIS format traffic information for external display on other
avionics that can receive traffic in TIS format. When this option is selected, only the actual TIS
traffic from a SV-XPNDR-261/262 is included in this serial data stream. This stream does not
include ADS-B, FLARM, Zaon, or other traffic sources that may be available to SkyView.
 Wire a serial transmit line from one display to the receive line on the external serial device.
If you have more than one SkyView display, make the same connection to all SkyView
displays.
 Ensure there is a shared ground between the SkyView display and the external serial device.
If you have more than one SkyView display, make the same connection to all SkyView
displays.
 Configure the serial port on the display appropriately under SETUP MENU > SYSTEM SETUP
> SERIAL PORT SETUP, SERIAL PORT x SETUP > TIS OUT (330 FORMAT).
USB Usage and Accessibility
It is useful to have the USB socket on the display’s wire harness accessible after
installation for file uploads and downloads.
The USB connector is used during the following operations:
 System Software updates
 Configuration file uploads and downloads
 Database updates
