AP Servo Installation, Configuration, and Calibration
SkyView System Installation Guide - Revision AA 10-3
Dynon Avionics Autopilot Servo Models
Dynon Avionics offers the following servo models:
Model Number
Torque
Attachment
SV32
36 inch-pounds
Standard Arm
SV32C
Capstan
SV32L
Long Arm
SV42
55 inch-pounds
Standard Arm
SV42C
Capstan
SV42EL
Extra Long
Arm
SV42L*
Long Arm
SV42T *
Torque
Enhancement
SV52
72 inch-pounds
Standard Arm
SV52C
Capstan
SV52L*
Long Arm
Table 73 – Dynon Avionics Servos
* SV42L, SV42T, and SV52L servos are special order items – contact Dynon Avionics for details.
Compass Calibration Requirement
The SkyView autopilot requires an accurate compass to operate efficiently and comfortably in
heading mode and the radio-based VOR/NAV mode. Therefore, it is critical that the ADAHRS be
installed correctly, calibrated, and operating well in all attitudes.
Additional Resources
Dynon Avionics’ Internet sites provide frequently updated information on installation and
operation issues:
Dynon Avionics’ Online Customer Forum –http://forum.dynonavionics.com – is a resource for
Dynon Avionics SkyView pilots to discuss installation and operation issues relating to Dynon
