Dynon Avionics SkyView Classic - Lycoming;Continental 6-Cylinder Fuel Injected

SV-EMS-220/221 Installation and Configuration
SkyView System Installation Guide - Revision AA 7-27
Lycoming/Continental 6-cylinder Fuel Injected
Table 39 and Table 40 below are suggested sensor connections for a Lycoming/Continental 6-
cylinder Fuel-Injected engine connected to an SV-EMS-220 EMS module.
Pin
EMS D37F Harness
Wire Color
Sensor
(with Dynon Avionics P/N if applicable)
1
Red
Battery voltage (voltmeter input)
2
Yellow or Unwired
No connection
3
Black
Ground
4
Violet/Blue
Elevator position potentiometer
5
Black
Ground
6
White/Yellow
Oil pressure P/N 101693-000
7
White/Brown
Oil temperature P/N 100409-000
8
Brown
Fuel pressure P/N 101716-000)
9
Brown/Blue
Heated AOA/Pitot Probe status (contact
input)
10
Brown/Yellow
No connection
11
Orange
No connection
12
Yellow
No connection
13
Black
Ground
14
Yellow
Fuel flow P/N 100403-003
15
Red
Fuel flow power P/N 100403-003
16
Black
Ground
17
Black
Ground
18
White/Red
Manifold Pressure Sensor Power (+5 volt) /
Kavlico Pressure Sensors
19
White/Black
No connection
20
Orange/Brown
Fuel level left (resistive)
21
Orange/Blue
Fuel level right (resistive)
22
Violet/Yellow
Flaps position potentiometer
23
Violet/Green
No connection
24
Orange/Green
Ammeter shunt + P/N 100412-000
25
Orange/Violet
Ammeter shunt - P/N 100412-000
26
Green/Red
Manifold Pressure P/N 100434-000
27
Open
No connection
28
Open
No connection
29
Yellow/Green
Optional External Alarm Indicator
30
Black
No connection
31
White/Orange
No connection
32
White/Green
RPM Left (standard)
33
White/Blue
RPM Right (standard)
34
Blue
No connection
35
Green
No connection
