31. Appendix K: Switches, etc. External to SkyView Units
Some SkyView units provide inputs or outputs for switches, other controls, indicators, etc. that
are installed external to the SkyView unit. Some of these are required (such as Servo Disconnect
/ CWS), while others provide optional, additional functionality. Table 130 below provides a
comprehensive listing of all external switches, etc. for reference in planning a SkyView panel,
stick grip, hat switches, etc.
Detailed installation instructions for the switch or indicator are included in the
section of this manual that the button, switch, or indicator is connected to.
SkyView Unit
Function
Pin
Number
Wire Color
Notes
Heated
AOA/Pitot Probe
Controller
Heated Pitot
Off or Failed
Warning
Indicator
N/A
White
Indicator
This signal can also be
connected to SV-EMS-
220/221 general purpose
input and displayed on
SkyView EMS page as a
contact.
Servo(s):
SV32(x)
SV42(x)
SV52(x)
Servo
Disconnect /
Control Wheel
Steering (CWS)
button
3
Yellow
Push Button Normally
Open (PBNO)
SV-AP-PANEL
Pilot Trim Up
Button
3
N/A
Push Button Normally
Open (PBNO)
Pilot Trim
Down Button
4
Copilot Trim Up
Button
5
Copilot Trim
Down Button
6
Pilot Trim Right
Button
10
Pilot Trim Left
Button
11
Copilot Trim
Right Button
12
Copilot Trim
Left Button
13
Copilot
Headset jacks
N/A
Headset jacks (pair); do
not connect to headset
