Appendix K: Switches, etc. External to SkyView Units
SkyView System Installation Guide - Revision AA 31-3
SkyView Unit
Function
Pin
Number
Wire Color
Notes
mount USB extension
cable(s)
SV-EMS-220
SV-EMS-221
EMS Warning
Indicator
29
Yellow/Green
Indicator
SV-INTERCOM-2S
Copilot Push To
Talk (PTT)
See
Wiring
Diagram
N/A
Push Button Normally
Open (PBNO)
Copilot
Headset jacks
N/A
Headset jacks (pair)
Music In Jack
11, 18, 24
N/A
Stereo 3.5mm jack or
direct connection to unit
Pilot Push To
Talk (PTT)
See
Wiring
Diagram
N/A
Push Button Normally
Open (PBNO)
Pilot Headset
Jacks
N/A
Headset jacks (pair)
Radio Select
(Transmit)
Switch
12
N/A
Single Pole Double Throw
(SPDT) Switch
SV-XPNDR-
261/262
Standby
17
N/A
Single Pole Single Throw
(SPST) Switch
Ident
Pushbutton
20
N/A
Push Button Normally
Open (PBNO)
Table 130 – Switches, etc. External to SkyView Units
