Appendix K: Switches, etc. External to SkyView Units
31-2 SkyView System Installation Guide - Revision AA
SkyView Unit
Function
Pin
Number
Wire Color
Notes
SV-COM-425
See
Wiring
Diagram
jacks if using SV-
INTERCOM-2S or other
audio panel.
Copilot Push To
Talk (PTT)
N/A
Push Button Normally
Open (PBNO); do not
connect to a button if
using SV-INTERCOM-2S or
other audio panel.
Pilot Headset
jacks
See
Wiring
Diagram
N/A
Headset jacks (pair); do
not connect to headset
jacks if using SV-
INTERCOM-2S or other
audio panel.
Copilot Push To
Talk (PTT)
N/A
Push Button Normally
Open (PBNO); do not
connect to a button if
using SV-INTERCOM-2S or
other audio panel.
SV-COM-PANEL
Flip/Flop
7
N/A
Push Button Normally
Open (PBNO)
SV-COM-X83
Push To Talk
(PTT)
15
N/A
Push Button Normally
Open (PBNO); do not
connect to a button if
using SV-INTERCOM-2S or
other audio panel.
SV-D600
SV-D700
SV-D900
SV-D1000
SV-D1000T
SV-KNOB-
DIMMER (Dim
Control Knob)
25
Violet
SV-KNOB-DIMMER
provides 0-36 VDC.
EXTERNAL
GO AROUND
button
27
Orange/Red
Push Button Normally
Open (PBNO) connect to
Ground.
External GO AROUND
Button is not supported in
SkyView SE.
SV-BUTTON-
LEVEL (LEVEL
Button)
28
Orange/Black
Push Button Normally
Open (PBNO) connect to
Ground.
USB (x2)
USB
jack(s) on
rear of
unit
N/A
For easy access to USB
jacks on rear of SkyView
display, install panel
