Accessory Installation and Configuration
15-24 SkyView System Installation Guide - Revision AA
retainers are properly retracted by pressing the outer release ring. This allows for connection,
disconnection, and reconnection of tubing easily with only one hand. A fresh cut of the tubing
with the supplied tubing cutter is recommended before re-inserting the tubing. With the use of
these Quick-Disconnect fittings, maintenance and instrument removal are made significantly
easier from the standpoint of a builder such as yourself.
Recommended Tools & Installation Accessories
Dynon Avionics has tried to provide you with as many parts and tools as necessary to make the
tasks involved in installing your Dynon Avionics Pitot/Static/AOA Pneumatic Installation Kit go
more smoothly. Tools that Dynon Avionics recommends for installations that use different
tubing are listed below along with an optional retailer to purchase them from if necessary.
Recommended Tools
Aviation Grade Flaring Tool (37 degrees)
www.aircraftspruce.com/catalog/topages/hidutyflaringtool.php?clickkey=4577
www.aircraftspruce.com/catalog/topages/flaringtools2.php?clickkey=4577
Or search “flaring tool” from any trusted aircraft retailer
Automotive or other non-aviation grade flaring tools will cause aluminum to work
harden and fail due to flaring in excess of 37 degrees. Dynon Avionics strongly
recommends using trusted tools designed specifically for aircraft.
Unique and additional fittings are available through Coast Pneumatics and can be ordered here-
http://www.coastpneumatics.com
Installation
Static Port
Two static ports are provided in the Dynon Avionics Pitot/Static/AOA Pneumatic
Installation Kit; one to mount on each side of the aircraft, to further increase
accuracy in pressure readings.
Static air pressure is obtained through both of the static port fittings mounted into the side of
the aircraft. The static port fittings should be mounted appropriately and in accordance with
the specific aircraft – in a place where the port can access relatively undisturbed air flow. The
static ports furnished as part of the Dynon Avionics Pitot/Static/AOA Pneumatic Installation Kit
are designed to be mounted “proud of” (slightly projecting from) the aircraft skin, in order to
provide more accurate readings.
After the placement of the static port is determined, verify there is enough room inside the
aircraft for the flange and fitting of the static port. Drill a ½” (12 mm) diameter hole from which
the static port will protrude. The circular groove on the back side of the port is meant to help
