SkyView Display Installation and Configuration
4-38 SkyView System Installation Guide - Revision AA
Example SkyView Serial Port Configuration for Icarus-Compatible Transponder
This example assumes that an Icarus format compatible transponder has been installed on
serial port 1.
1. Enter the Serial Port 1 Setup Menu (SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP >
SERIAL PORT 1 SETUP).
2. Set serial 1 input device to NONE (SERIAL 1 IN DEVICE: NONE).
3. Set serial 1 in function to NONE (SERIAL 1 IN FUNCTION: NONE).
4. Set serial 1 baud rate to 9600 (SERIAL 1 IN/OUT BAUD RATE: 9600)
5. Set serial 1 output device to ICARUS (100ft) or ICARUS (10ft) (SERIAL 1 OUT DEVICE: ICARUS
(100ft) or ICARUS (10ft).
6. Press BACK or EXIT to save the settings.
Brightness Setup
Enter the Brightness Setup Page (SETUP MENU > LOCAL DISPLAY SETUP > BRIGHTNESS SETUP)
to characterize the display’s backlight behavior. The backlight level can be adjusted manually by
the user (not supported in SkyView SE), automatically by the display based on ambient light
conditions, or by an external control signal while on the Brightness Setup Page and in normal
flight. Regardless of the specified control method, users always have the option of manually
adjusting the backlight level in the Dim Menu.
Automatic Brightness Management
To set the backlight level so that it automatically adjusts, set BRIGHTNESS SOURCE to INTERNAL
(ZERO OFFSET) or INTERNAL (LAST) depending on whether you want the brightness setting to
reset when SkyView is started, or you want the bright setting from SkyView’s last use to be
used when SkyView is started. When this option is selected, dimming is normally controlled
automatically via ambient light detection, but it can also be controlled manually by using the
DIM Menu. Dynon Avionics has created a default dimming profile that should work well in most
aircraft. If you find that this profile does not work well in your installation, it can be customized
to suit your preferences using the tools on the BRIGHTNESS SETUP Menu. This menu displays
several parameters, which are listed and briefly explained below.
 LOCAL BRIGHTNESS SENSOR – This is an integer value ranging from 0 to 999 that represents
the amount of light sensed by the display’s integrated light sensor. Use this value to
characterize the ambient light levels in your installation during characterization.
 BRIGHTNESS TARGET – This is a percentage ranging from 0% to 100% that represents the
calculated target backlight level based on the sensed ambient light level and the percent
brightness sensor value map. The actual brightness never drops below 20% when the
Brightness Setup Page is displayed, even though the target value may be below 20%.
