System Planning
SkyView System Installation Guide - Revision AA 2-7
Unit
Dimensions
Weight
SV-HDX1100
10.31” W x 7.1” H x 3.1” D
(262mm W x 180mm x 79mm D)
3.35 lb. (1.52 kg)
SV-KNOB-PANEL
3.53” x 1.80” x 1.27” D
(89.7mm x 45.7mm H x 32.4mm D)
0.40 lb. (0.18 kg)
SV-MAG-236
4.71” W x 1.22” H x 2.61” D
(120mm W x 31mm H x 66mm D)
(not including cable - 18” (457mm)
0.46 lb. (0.21 kg)
SV-XPNDR-261/262
(w/mounting tray)
2.5” W x 1.9”H x 6.3” D
(66mm W x 48mm H x 160mm D)
0.77 lb. (0.35 kg)
Table 5 – SkyView System Component Physical Specifications
Temperature Specifications
Table 6 contains environmental specifications for major SkyView units.
Environmental Specifications
Storage Temperature
Operating Temperature
SV32 (all variants)
SV42 (all variants)
SV52 (all variants)
-22° F to 167° F
(-30° C to 75° C)
-22° F to 140° F
(-30° C to 60° C)
SV-ADAHRS-200
SV-ADAHRS-201
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-ADSB-470
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to +60° C)
SV-AP-PANEL
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-ARINC-429
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to +60° C)
SV-BAT-320
-4° F to 140° F
(-20° C to 60 °C)
-4° F to 140° F
(-20° C to 60° C)
SV-COM-C25
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-COM-X83
-67° F to 185° F
(-55° C to 85° C)
-4° F to 158° F
(-20° C to 70° C)
SV-D600
SV-D700
SV-D900
SV-D1000
SV-D1000T
SV-HDX800
SV-HDX1100
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
SV-EMS-220
SV-EMS-221
-40° F to 158° F
(-40° C to 70° C)
-22° F to 140° F
(-30° C to 60° C)
