SV-EMS-220/221 Installation and Configuration
SkyView System Installation Guide - Revision AA 7-35
Rotax 912 iS (Electronic Control Unit)
Table 45 below is the suggested sensor connections for a Rotax 912 iS engine connected to an
SV-EMS-221 EMS module. Note that the Rotax 912 iS engine does not utilize thermocouple
sensors to monitor CHT and EGT temperatures on the SV-EMS-221 EMS module, thus there is
no connection to the D25F connector on the SV-EMS-221.
Pin
EMS D37F Harness
Wire Color
Sensor
(with Dynon Avionics P/N if applicable)
1
Red
Battery voltage (voltmeter input)
2
Yellow or Unwired
No connection
3
Black
Available ground
4
Violet/Blue
No connection
5
Black
Available ground
6
White/Yellow
No connection
7
White/Brown
No connection
8
Brown
Fuel pressure (101716-000)
9
Brown/Blue
No connection
10
Brown/Yellow
No connection
11
Orange
No connection
12
Yellow
Flaps position potentiometer
13
Black
Available ground
14
Yellow
Fuel flow P/N 100403-003
15
Red
Fuel flow power P/N 100403-003 / Oil pressure
(Honeywell and Rotax P/N 456180 only) sensor
power
16
Black
Available ground
17
Black
Available ground
18
White/Red
Manifold Pressure Sensor Power (+5 volt) / Kavlico
Pressure Sensors
19
White/Black
Return fuel flow P/N 100403-003
20
Orange/Brown
Fuel level left (resistive)
21
Orange/Blue
Fuel level right (resistive)
22
Violet/Yellow
No connection
23
Violet/Green
Elevator position potentiometer
24
Orange/Green
Ammeter shunt + P/N 100412-000
25
Orange/Violet
Ammeter shunt - P/N 100412-000
26
Green/Red
No connection
27
Open
RPM Signal to Rotax 912 iS Prop Controller
(optional)
28
Open
NOTE: Must be grounded to common ground with
Prop Controller
29
Yellow/Green
Optional External Alarm Indicator
30
Black
No connection
31
White/Orange
No connection
32
White/Green
No connection
33
White/Blue
No connection
