SV-EMS-220/221 Installation and Configuration
7-34 SkyView System Installation Guide - Revision AA
37
Green or Unwired
No connection
Table 45 – Suggested Rotax 912 ULS Carbureted Sensor Connections for EMS D37F Harness
Pin
EMS D25M Thermocouple
Harness Wire Color
Sensor
(with Dynon Avionics P/N if applicable)
1
Open
N/A
2
Open
N/A
3
Open
N/A
4
Open
N/A
5
Open
N/A
6
Red
N/A
7
Red
N/A
8
Red
N/A
9
Red
N/A
10
Red
N/A
11
Red
EGT 2 (K-type thermocouple, 100405-000*)
12
Red
N/A
13
Red
EGT 1
14
Open
N/A
15
Open
N/A
16
Open
N/A
17
Open
N/A
18
White
N/A
19
Yellow
N/A
20
White
N/A
21
Yellow
N/A
22
White
N/A
23
Yellow
EGT 2
24
White
N/A
25
Yellow
EGT 1
Table 46 – Suggested Rotax 912 ULS Carbureted Sensor Connections for EMS D25M Harness
* Note that J-type and K-type thermocouples apply to all CHTs or EGTs, respectively. They are
not repeated in the table for brevity’s sake.
