22. Appendix B: Specifications
SkyView / Dynon Avionics Minor Equipment Weights
For Major Equipment Weights, see System Planning, Major Unit Physical Specifications.
SkyView / Dynon Avionics Equipment Description
Approx. Weight
Ammeter Shunt P/N 100412-000
0.32 lb. (0.14 kg)
AOA/Pitot Probe, unheated (100141-000)
0.36 lb. (0.16 kg)
Antenna – 978 MHz (for ADS-B)
0.05 lb. (0.02 kg)
Antenna – 1090 MHz (for Transponder)
0.05 lb. (0.02 kg)
AOA/Pitot Probe, heated with controller (100667-000)
0.71 lb. (0.32 kg)
AOA/Pitot Boom Probe, unheated (100532-000)
0.27 lb. (0.12 kg)
Carburetor Air Temperature Sensor P/N 100468-000
0.13 lb. (0.06 kg)
Capacitance to Voltage Converter (100654-000) (single)
0.08 lb. (0.04 kg)*
CHT Sensor (100404-000) (single)
0.08 lb. (0.04 kg)*
CHT Sensor (100578-000) (single)
0.04 lb. (0.02 kg)*
EGT Sensor (100405-000, -001, -002) (single)
0.09 lb. (0.04 kg)*
EMS 37-pin Main Sensor Harness (100399-000)
0.81 lb. (0.37 kg)
EMS EGT-only 2-cylinder 25-pin Thermocouple Wire Harness (100399-004)
0.22 lb. (0.10 kg)
EMS EGT/CHT 4-cylinder 25-pin Thermocouple Wire Harness (100399-001)
0.71 lb. (0.32 kg)
EMS EGT/CHT 6-cylinder 25-pin Thermocouple Wire Harness (100399-002)
0.69 lb. (0.31 kg)
Encoder Converter Module, Serial-to-Gray Code (100362-000)
0.10 lb. (0.05 kg)
Fluid Pressure Sensor – Kavlico, with pigtail (101690-000, 101691-000,
101715-000, 101716-000, 101692-000, 101693-000)
0.11 lb. (0.05 kg)*
Fluid Pressure Sensor – VDO-style (legacy)
(100409-000, 100409-001, and 100409-002)
0.13 lb. (0.06 kg)
Fuel Flow Transducer P/N 100403-003 (single)
0.24 lb. (0.11 kg)*
Manifold Pressure Sensor P/N 100434-000
0.20 lb. (0.09 kg)
OAT Sensor (100433-000) / SV-OAT-340 (100433-003)
0.09 lb. (0.04 kg)
SV-ETHERNET-3CC
0.07 lb. (0.03 kg)
SV-HARNESS-D37
0.47 lb. (0.21 kg)
SV-NET-1.5CC
0.16 lb. (.071 kg)
SV-NET-3CC
0.21 lb. (0.10 kg)
SV-NET-6CC
0.33 lb. (0.15 kg)
SV-NET-10CP
0.49 lb. (0.22 kg)
SV-NET-15CP
0.68 lb. (0.31 kg)
SV-NET-20CP
0.87 lb. (0.40 kg)
SV-NET-25CP
1.07 lb. (0.49 kg)
SV-NET-30CP
1.26 lb. (0.57 kg)
SV-NET-HUB
0.19 lb. (0.09 kg)
SV-NET-SERVO
0.70 lb. (0.32 kg)
SV-NET-SPL
0.20 lb. (0.09 kg)
SkyView Video Input Adapter (102211-000)
0.19 lb. (0.06 kg)*
SkyView Wi-Fi Adapter with pigtail (102045-000)
0.06 lb. (0.02 kg)*
Table 99 – SkyView Minor Equipment Weights
