SV-GPS-250/2020 GPS Receiver Installation and Configuration
8-10 SkyView System Installation Guide - Revision AA
Configuration – SV-GPS-2020 only, Serial Port 5
Go to the Serial Port Setup Menu (SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP >
SERIAL PORT 5 SETUP) and then configure serial port 5 as follows:
SERIAL IN DEVICE: DYNON SV-GPS-2020
SERIAL IN FUNCTION: POS 1
NAVIGATION SOURCE DISPLAY NAME: (NOT SET)
SERIAL IN/OUT BAUD RATE: 115,200
SERIAL OUT DEVICE: DYNON SV-GPS-2020
(Highlighted settings are changed automatically from SERIAL IN DEVICE.)
Configuration – SV-GPS-2020 (Serial Port 5) and SV-GPS-250 (Serial Port 4)
The following configuration uses Serial Port 4 for the (secondary) SV-GPS-250 as shown in
Figure 94 – SV-GPS-2020 and SV-GPS-250 Connected to Multiple Displays. As explained there,
use of Serial Port 4 for the SV-GPS-250 (secondary GPS) is for illustration only. Serial Port 1, 2, 3,
or 4 (if available) may be used for the SV-GPS-250 (secondary GPS).
Go to the Serial Port Setup Menu (SETUP MENU > SYSTEM SETUP > SERIAL PORT SETUP
Configure Serial Port 5 as follows:
SERIAL IN DEVICE: DYNON SV-GPS-2020
SERIAL IN FUNCTION: POS 1
NAVIGATION SOURCE DISPLAY NAME: (NOT SET)
SERIAL IN/OUT BAUD RATE: 115,200
SERIAL OUT DEVICE: DYNON SV-GPS-2020
(Highlighted settings are changed automatically from SERIAL IN DEVICE.)
Configure Serial Port 4 as follows:
SERIAL IN DEVICE: DYNON SV-GPS-250
SERIAL IN FUNCTION: POS 2
NAVIGATION SOURCE DISPLAY NAME: (NOT SET)
SERIAL IN/OUT BAUD RATE: 38,400
SERIAL OUT DEVICE: NONE
(Highlighted settings are changed automatically from SERIAL IN DEVICE.)
In SkyView Software v14.0 and earlier, when a serial port’s SERIAL IN DEVICE is set
to DYNON SV-GPS-250 or DYNON SV-GPS-2020 (typically SERIAL PORT 5), the
SERIAL OUT DEVICE for that serial port is not “auto-assigned” – it was possible to
select a different serial device in SERIAL OUT DEVICE.
In Software versions v14.0 and later, when a serial port’s SERIAL IN DEVICE is set
to DYNON SV-GPS-2020, SERIAL OUT DEVICE for that serial port is “auto-assigned”
to DYNON SV-GPS-2020 respectively. Selection of SV-GPS-250 allows a different
SERIAL OUT DEVICE.
