SV-GPS-250/2020 GPS Receiver Installation and Configuration
SkyView System Installation Guide - Revision AA 8-7
At the SkyView display(s), splice the Black wire of the SV-GPS-250 to the Black wire of
the SV-GPS-2020.
Connect the SV-GPS-2020’s Gray/Violet (TX) wire to Serial Port 1, 2, 3, or 4 RX wire.
Connect the SV-GPS-2020’s Gray/Orange (RX) wire to Serial Port 1, 2, 3, or 4 TX wire.
Change configuration of the SV-GPS-250 (Serial Port 5) to POS 2.
Configure the serial port used for the SV-GPS-2020 to POS 1.
Serial Data Connection
For its primary source of GPS data, SkyView uses the GPS data from the device set
to SERIAL IN FUNCTION: POS 1.
If your installation has two or more displays, all four wires of the SV-GPS-250
and/or SV-GPS-2020 must be connected to all displays.
The SV-GPS-250/2020 includes 18 feet (5.49 meters) of twisted wire for a serial connection to
the SkyView display via the display. This wire may be trimmed or lengthened as needed to suit
the installation the length of these wires is not critical.
The color of the SV-GPS-250/2020 wires matches the colors of the wires of the SV-HARNESS-
D37 that are intended for the GPS serial connection. The following table contains information
regarding the wires.
Function
SkyView Display Harness
SV-GPS-250/2020
Wire Color
SkyView
Display
D37 Pin
SV-GPS-250/2020 TX
Gray with
Violet stripe
11
SkyView display
Serial Port 5 RX
SV-GPS-250/2020 RX
Gray with
Orange stripe
12
SkyView display
Serial Port 5 TX
SV-GPS-250/2020
Ground
Black
24
SV-GPS-250/2020
Power
Orange
29
Table 69 SV-GPS-250/2020 Serial Connection Details
As mentioned previously, if there are two or more displays in your SkyView system, all four of
the SV-GPS-250/2020’s wires must be connected to all displays in parallel. This wiring scheme is
illustrated in Figure 93.
