Basic SkyView Display Operation
3-16 SkyView System Installation Guide - Revision AA
TERRAIN WARNING COLORS Sets whether Red and Yellow terrain warning are provided on
the Map Page
RED AND YELLOW START When the above setting is set to “YES”, these settings how far
above or below the aircraft’s current altitude the red and yellow colors persist.
AUTOPILOT SETUP Menu
This menu is not accessible until the autopilot servos in the system have been
successfully calibrated and tested. Reference the Autopilot Servo Calibration and
Test Procedures Section of this guide for more information.
This menu configures various aspects of the Dynon Avionics Autopilot system.
STATUS Displays diagnostic / troubleshooting information for the AP system.
AUTOPILOT CONTROLS Chooses the EXPERT or SIMPLIFIED mode. Note that the EXPERT
mode must be selected for the Dynon Avionics SV-AP-PANEL to be active.
ROLL AXIS Roll axis setup and tuning parameters.
PITCH AXIS Pitch axis setup and tuning parameters.
DISENGAGE BUTTON Configure disengage button options such as hold to engage, enable
broken line detect, and control wheel steering mode.
FLIGHT DIRECTOR Chooses the SINGLE CUE (INVERTED V) or DUAL CUE (CROSS BARS)
mode of flight director to be displayed on the PFD.
TRANSPONDER SETUP Menu
This menu is not accessible unless a SV-XPNDR-261/262 is setup and configured.
Reference the SV-XPNDR-261/262 Installation and Configuration Section of this
guide for more information.
This menu contains options that are used to set up and configure the SV-XPNDR-261/262
module.
HARDWARE CALIBRATION Menu
This menu contains links to the following menus:
ADAHRS CALIBRATION Enter this menu to make altitude adjustments (e.g., baro and
altitude offset) and access the compass and AOA calibration wizards.
EMS CALIBRATION Enter this menu for EMS sensor calibration. You will have options to
calibrate fuel tanks and position potentiometers that have been mapped in the Sensor Input
Mapping Wizard. Calibration wizards contain onscreen instructions.
AP SERVO CALIBRATION Enter this menu for autopilot servo calibration. Reference the AP
Servo Installation, Configuration, and Calibration Section of this guide for more details.
TRIM MOTOR CONFIGURATION Enter this menu to configure one or two trim motors
(connected to / powered by the Dynon Avionics SV-AP-PANEL 15-pin connector) for
automatic trim control (Autopilot Auto-trim) during AP operation. Reference the Autopilot
Auto-trim Section of the SV-AP-PANEL Installation section of this guide for more details.
