SV-EMS-220/221 Installation and Configuration
7-74 SkyView System Installation Guide - Revision AA
 0-1400 and 5800-6000 RPM in RED
 1400-1800 and 5500-5800 RPM in YELLOW
 1800-5500 RPM in GREEN
At 0 RPM, tachometer alerting is inhibited. When RPM advances above 0, the tachometer alert
is inhibited for 10 seconds to avoid nuisance alarms as the engine starts.
The alarm type for the tachometer is the “self-clearing” type.
Oil Temperature Gauge for Rotax 912:
When OIL TEMP < 190°F, the OIL TEMP gauge displays these ranges:
 100-120 and 230-266° F in YELLOW
 120-190° F in GREEN if OIL TEMP has been above 190° F “more recently” than OIL TEMP was
below 120° F; otherwise 120-190° F is displayed in BLACK OUTLINED IN WHITE
 190-230° F in GREEN
 266-280° F in RED.
When OIL TEMP is > 190° F, the OIL TEMP gauge will display different ranges:
 100-120 and 230-266° F in YELLOW
 120-230° F in GREEN
 266-280° F in RED
The alarm type for oil temperature is the “self-clearing” type.
EMS Sensor Definitions, Mapping, and Settings
All sensors must be defined, mapped to SV-EMS-220/221 pins, and have their
settings configured. This section describes how sensors are defined, mapped, and
set in SkyView.
EMS Sensor Definitions
All EMS sensor installations require a SkyView Sensor Definitions file. This file provides
characterizations of all sensors that SkyView supports, and is occasionally updated to add
additional supported sensors and correct issues with existing sensors. The most current version
of the SkyView Sensor Definitions file is preloaded onto each display prior to shipment. The
most current version of the SkyView Sensor Definitions file can be downloaded from
http://downloads.dynonavionics.com. If you have more than one SkyView display, and the
SkyView Sensor Definitions file on each display is different from one another, a Warning
message will be displayed:
EMS SFG FILE MISMATCH.
If you need to update the SkyView Sensor Definitions file, download the file and use the
instructions found in the How to Load and Delete Files Section.
