Appendix B: Specifications
22-6 SkyView System Installation Guide - Revision AA
s – Surveillance Identifier (SI) code. Used by
Mode S transponders and Mode S equipped
SSR to limit interrogations to specific
transponders.
FCC Identification
VZI00675
Applicable documents
EUROCAE ED-73C, EUROCAE ED-14F (RTCA DO-
160F), RTCA DO-181D, RTCA DO-260B
Software
ED-12B (RTCA DO-178B) Level B
Hardware
DO-254 Level C
Power Requirements
11 – 33 Volts DC. Typical 5 Watts @ 14Volts.
Altitude
< 15,000 feet
Speed
< 175 knots
Humidity
95% @ +50°C for 6 hours; 85% @ +38°C for 16
hours.
Tested to Category A in DO-160F
Operating
Temperature
-20°C to +70°C
Transmitter Frequency
1090MHz ± 1MHz
Transmitter Power
125 Watts nominal; 71 Watts minimum at
antenna after allowing for 0.5dB connector
losses and 1.5dB cable losses.
Transmitter
Modulation
6M75 V1D
Receiver Frequency
1030 MHz
Receiver Sensitivity
-74Dbm ± 3Db
Physical Specifications (in the mounting tray)
Height
48mm (1.9”)
Width
66mm (2.5”)
Length
160mm (6.3”)
Weight
0.77lbs. (350 g)
Table 103 – SV-XPNDR-262 Specifications
SV-XPNDR-261/262 Environmental Qualification Forms
Nomenclature:
TT21 Mode S Transponder (Dynon Avionics SV-XPNDR-262)
Part Number: 00675-(XX)
ETSO: 2C112b, C166a
Manufacturer:
Trig Avionics Limited
Address:
Heriot Watt Research Park, Riccarton, Currie, Scotland, EH14 4AP
Conditions
DO-160F
Section
Description of Conducted Tests
Temperature and Altitude
4.0
Equipment tested to Categories A2, C1
Low temperature ground survival
4.5.1
-55°C
Low temperature short-time
operating
4.5.1
-40°C
Low temperature operating
4.5.2
-20°C
High temperature operating
4.5.4
+70°C
High temperature short-time
operating
4.5.3
+70°C
High temperature ground survival
4.5.3
+85°C
