SV-XPNDR-261/262 Installation and Configuration
11-14 SkyView System Installation Guide - Revision AA
Max Length
in Meters
Max
Length
in Feet
Insertion Loss
dB/meter at
1090MHz
MIL-C-17
Cables
Electronic
Cable
Specialists
Type
SSB
Electronic
2.54
8’ 4”
0.59
M17/128
(RG400)
3.16
10’ 4”
0.47
3C142B
3.81
12’ 6”
0.39
M17/112
(RG304)
4.50
14’ 9”
0.33
Aircell 5
5.25
17’ 3”
0.29
M17/127
(RG393)
311601
6.42
21’ 1”
0.23
311501
6.81
22’ 4”
0.22
Aircell 7
8.22
26’ 11”
0.18
311201
12.59
41’ 3”
0.12
310801
Table 77 – Maximum Usable Lengths of Some Common Coaxial Cable Types
Contact Electronic Cable Specialists on +1 414 421 5300 or at http://www.ecsdirect.com for
their data sheets. Contact SSB-Electronic GmbH on +49-2371-95900 or at http://www.ssb.de
for their data sheets.
When routing the cable, ensure that you:
 Route the cable away from sources of heat.
 Route the cable away from potential interference sources such as ignition wiring, 400Hz
generators, fluorescent lighting and electric motors.
 Allow a minimum separation of 300 mm (12 inches) from an ADF antenna cable.
 Keep the cable run as short as possible.
 Avoid routing the cable around tight bends.
 Avoid kinking the cable even temporarily during installation.
 Secure the cable so that it cannot interfere with other systems.
Antenna TNC Female Connector
This section describes the technique for attaching the antenna cable to a TNC Male connector.
A TNC Male connector is not supplied with the SV-XPNDR-261/262. The SV-XPNDR-261/262 has
