SV-ARINC-429 Installation and Configuration
SkyView System Installation Guide - Revision AA 12-5
Pin
Function
Notes
1
No Connect
-
2
No Connect
-
3
Serial RX
Aviation Format Only from Connected ARINC-429 GPS
4
No Connect
-
5
No Connect
-
6
No Connect
-
7
No Connect
-
8
No Connect
-
9
No Connect
-
10
ARINC 2 RX B
-
11
ARINC 1 RX B
-
12
ARINC TX B
Pins 12/13 are the same TX signal. Provided for
convenience when connecting to multiple ARINC receivers.
13
ARINC TX B
Pins 12/13 are the same TX signal. Provided for
convenience when connecting multiple ARINC receivers.
14
No Connect
-
15
No Connect
-
16
No Connect
-
17
No Connect
-
18
No Connect
-
19
No Connect
-
20
Ground
-
21
No Connect
-
22
ARINC 2 RX A
-
23
ARINC 1 RX A
-
24
ARINC TX A
Pins 24/25 are the same TX signal. Provided for
convenience when connecting multiple ARINC receivers.
25
ARINC TX A
Pins 24/25 are the same TX signal. Provided for
convenience when connecting multiple ARINC receivers.
Table 80 – SV-ARINC-429 Pinout
