Accessory Installation and Configuration
15-2 SkyView System Installation Guide - Revision AA
RANGE 3, RANGE 4, RANGE 5
ENABLE: NO
(other parameters are ignored when ENABLE set to NO)
4. SETUP MENU > EMS SETUP > SCREEN LAYOUT EDITOR
SENSOR (button)
Select PHEAT (or custom name) CONTACT
ACCEPT (button)
Adjust size of the icon to your preference.
Adjust location of the icon to your preference.
SAVE (button)
5. Repeat step 5 for 20%, 50%, and 100% layouts as desired
6. Test:
When Pitot Heater Controller is OFF (or fault), EMS screen should display RED indicator
with text OFF (or your preferred text).
When Pitot Heater Controller is ON, EMS screen should display GREEN indicator
with text ON (or your preferred text).
Angle of Attack Audio Alert Volume
To adjust the volume of the AOA Audio Alert: SETUP MENU > SYSTEM SETUP > AUDIO SETUP >
AOA VOLUME: (0% TO 100%). Note that AOA VOLUME is a percentage of the audio level of
MASTER VOLUME CONTROL. Example 1: If MASTER VOLUME CONTROL is set to 50%, and AOA
VOLUME is set to 100%, the volume AOA Audio Alerts will be the same as all other audio from
the SkyView system. Example 2: If MASTER VOLUME CONTROL is set to 100%, and AOA
VOLUME is set to 50%, the volume AOA Audio Alerts will be approximately half as loud as all
other audio from the SkyView system.
In-flight AOA Calibration
It is your responsibility to fly your plane safely while performing any configuration
or calibration in flight. The best scenario includes a second person to perform any
necessary steps on any SkyView components.
Detailed instructions on calibrating the Dynon Avionics AOA/Pitot Probe as installed on your
plane, for your plane’s particular flight characteristics, are provided on-screen on the SkyView
display. You can preview the instructions prior to a flight: SETUP MENU (push buttons 7+8
together), then HARDWARE CALIBRATION > ADAHRS CALIBRATION > AOA CALIBRATION, as
shown in Figure 162 below.
If your panel is equipped with multiple SkyView displays, the AOA Calibration
procedure can be performed from any SkyView display, including a SkyView
display that is not configured to display PFD. As shown Figure 162 below, entering
the AOA Calibration menu automatically, temporarily, reconfigures that SkyView
display for Primary Flight Display on the left half, and the AOA Calibration
