Appendix C: Wiring and Electrical Connections
SkyView System Installation Guide - Revision AA 23-21
The SV-COM-425-uses a D15M connector for connecting to the SV-COM-PANEL. Figure 226
above shows the pin numbering for the mating D15F connector, installed on the cable that
plugs into this connector, from the rear (pin insertion) view.
Pin
Wire Color
Function
Notes
1
(determined by installer)
MICROPHONE
IN
To SV-COM-2S Pin 25
2
(determined by installer)
MICROPHONE
/ PTT GROUND
GROUND
3
(determined by installer)
SV-COM-
PANEL ENABLE
To SV-COM-PANEL Pin 6
4
(determined by installer)
GROUND OUT
Optional Ground available for use
5
(determined by installer)
PTT IN
To SV-INTERCOM-2S Pin 12 or
Push Button Normally Open (PBNO)
to Ground (Pins 4, 11, or 15)
6
(determined by installer)
DATA TX TO
SV-COM-
PANEL
To SV-COM-PANEL Pin 4
7
(determined by installer)
SV-COM-
PANEL POWER
To SV-COM-PANEL Pin 1
8
Red
POWER IN
10 30V DC @ 5A
9
(determined by installer)
PHONES
GROUND
SV-COM-425 Pin 2
SV-INTERCOM-2S Pin 1
Shielded Cable – shield of Pin 10
10
(determined by installer)
PHONES OUT
SV-INTERCOM-2S Pin 14
Shielded cable – center conductor of Pin 10
11
(determined by installer)
GROUND OUT
Optional Ground available for use
12
Black
GROUND IN
Ground Bus
13
(determined by installer)
SV-COM-
PANEL
GROUND
To SV-COM-PANEL Pin 2
14
(determined by installer)
DATA RX
FROM SV-
COM-PANEL
To SV-COM-PANEL Pin 5
15
(determined by installer)
GROUND OUT
Optional Ground available for use
Table 123 – SV-COM-425 D15M Connector
