Appendix C: Wiring and Electrical Connections
SkyView System Installation Guide - Revision AA 23-23
18
(determined by installer)
TRANSMIT
INTERLOCK
(Use only when there are two SV-COM-X83s
installed.) Connect to other radio’s PTT.
19
(determined by installer)
GROUND IN
GROUND
20
N/A
No Connection
-
21
N/A
No Connection
-
22
(determined by installer)
GROUND IN
GROUND
23
(determined by installer)
MICROPHONE IN
Connect to SV-INTERCOM-2S Pin 25
(inside shielded cable)
24
(determined by installer)
POWER IN
10-30V DC @ 5A
25
(determined by installer)
POWER IN
10-30V DC @ 5A
Table 124 – SV-COM-T8 D25M Connector
