Appendix E: Serial Data Output
SkyView System Installation Guide - Revision AA 25-3
Position
Width
Name
Description
34
4
Turn Rate (deg/s)
+/- then 000 to 999, rate of yaw change in
degrees/second * 10, positive meaning the
aircraft is turning right. XXXX when not
available.
38
3
Lateral Accel (g)
+/- then 00 to 99, lateral g’s in units of g * 100
(99 = 0.99 g’s), positive meaning the aircraft is
experiencing leftward lateral acceleration (slip
/ skid ball is deflected to the right). XXX when
not available.
41
3
Vertical Accel(g)
+/- then 00 to 99, vertical g’s in units of g * 10
(99 = 9.9 g’s), positive meaning the aircraft is
experiencing upward vertical acceleration. XXX
when not available.
44
2
Angle of Attack (%)
00 to 99, percentage of critical angle of attack.
XX when not available.
46
4
Vertical Speed
(ft./min)
+/- then 000 to 999, feet/minute / 10 (42 = 420
feet per minute), positive meaning the aircraft
is climbing. XXX when not available.
50
3
OAT (deg C)
+/- then 00 to 99. Outside Air Temperature in
Degrees C. XXX when not available.
53
4
True Airspeed
(knots)
0000 to 9999, true airspeed in units of knots *
10 (1234 = 123.4 knots). XXXX when not
available.
57
3
Barometer Setting
(inHg)
000 to 400. Baro setting in inHg * 100, offset by
27.50 inHg. Total range is 27.50 inHg to 31.50
inHg. (242 = 29.92 inHg). XXX when not
available.
60
6
Density Altitude
(ft.)
+/- then 00000 to 99999, altitude in units of
feet, positive meaning altitude is above sea-
level. XXXXXX when not available.
66
3
Wind Direction
(deg)
000 to 359. Wind direction in degrees
magnetic. XXX if unknown.
69
2
Wind Speed
(knots)
00 to 99. Wind Speed in Knots. XX if unknown.
71
2
Checksum
The 1 byte sum of all 70 preceding bytes. In
ascii-hexformat, so 3A = 0x3A
73
2
CR/LF
Carriage Return, Linefeed = 0x0D, 0x0A.
Table 125 – SkyView ADAHRS Serial Data Output Format
As an example, the following is one line of DYNON ADAHRS serial output data:
