SV-XPNDR-261 Transponder Installation and Configuration
12-8 SkyView HDX System Installation Manual - Revision E
The figure below shows a typical set of connections for the SV-XPNDR-261 D25
connector, as viewed from the wiring side of the D25 connector:
Figure 76: Typical SV-XPNDR-261 Connections (Rear Pin Insertion View)
The figure below shows all possible connections, as viewed from the wiring side of the
D25 connector:
Figure 77 – All Possible SV-XPNDR-261 Connections (Rear Pin Insertion View)
