The SV-COM-PANEL has two (2) (electrically identical) D9M connectors for connection
to SkyView Network and one (1) D15M connector for connection with the transceiver and
an optional Frequency Flip/Flop pushbutton input.
The transceiver has one (1) D15M connector for connection to the SV-COM-PANEL,
power, audio, and Push to Talk (PTT). A TNC connector attaches to the antenna.
15.2.5.2 SV-COM-PANEL – D15M Pinout
Table 39: SV-COM-PANEL D15M Pinout
Pin
Function
Notes
1
Power In
From SV-COM-C25 Pin 7
2
Ground In
From SV-COM-C25 Pin 13
3
Ground Out
Optional - For Grounding Pin 7
(Flip/Flop Switch). Switch may also
be grounded locally.
4
Panel RX / C25 TX
From SV-COM-C25 Pin 6
5
Panel TX / C25 RX
From SV-COM-C25 Pin 14
6
Enable
From SV-COM-C25 Pin 3
7
External Flip/Flop
(optional)
Push Button Normally Open to
Ground (Pin 3 or local ground)
8
No Connection
(Pin not used)
9
No Connection
(Pin not used)
10
No Connection
(Pin not used)
11
No Connection
(Pin not used)
12
No Connection
(Pin not used)
13
No Connection
(Pin not used)
14
No Connection
(Pin not used)
15
No Connection
(Pin not used)
