SV-COM-X83 Transceiver and Panel Installation and Configuration
SkyView HDX System Installation Manual - Revision E 15-7
15.2.5.3 Transceiver – D25M Pinout
Table 40: SV-COM-PANEL D25M Pinout
Pin
Function
Notes
1
Phones Ground
To Audio Panel
2
Phones Out
To Audio Panel
3
-
Not Used
4
-
Not Used
5
Data RX
SV-COM-PANEL pin 5
6
Data TX
SV-COM-PANEL pin 4
7
-
Not Used
8
-
Not Used
9
MIC/PTT Ground
MIC/PTT sheild
10
Ground
11
-
Not Used
12
-
Not Used
13
SV-COM-PANEL Enable
SV-COM-PANEL pin 6
14
-
Not Used
15
PTT In
Push button normally open (PBNO) to ground
16
-
Not Used
17
-
Not Used
18
Transmit Interlock
Dual SV-COM-X83 installation only
19
Ground In
Airframe ground
20
-
Not Used
21
-
Not Used
22
Ground In
Airframe ground
23
MIC In
From Audio Panel
24
Power In
10-30v dc from source
25
Power In
10-30v dc from source
15.2.5.4 Power/Ground Input
The transceiver and SV-COM-PANEL require 10-30V DC. 20 AWG wire is recommended
for power and ground wires for the transceiver. For all other connections, 22 AWG wire
is recommended.
