Appendix C: Wiring and Electrical Connections
25-12 SkyView HDX System Installation Manual - Revision E
SV-EMS-220
D37M Pin
EMS 37-pin Harness Wire
Color
Description
31
White/Orange
Enhanced General Purpose Input 13
32
White/Green
Standard RPM Left Input
33
White/Blue
Standard RPM Right Input
34
Blue
Low Voltage RPM Left Input
35
Green
Low Voltage RPM Right Input
36
Blue
General Purpose TC Input 2+
37
Green
General Purpose TC Input 2-
Table 69: SV-EMS-221 D37M Connector
SV-EMS-221 D37
Pin
EMS 37-pin Harness Wire
Color
Sensor (with Dynon Avionics part
number if applicable)
1
Red
Voltmeter 1 (0 to 30 volts DC)
2
Yellow or Unwired
Voltmeter 2 (0 to 30 volts DC)
3
Black
Signal Ground
4
Violet/Blue
General Purpose Input 1
5
Black
Signal Ground
6
White/Yellow
General Purpose Input 11
7
White/Brown
General Purpose Input 12
8
Brown
Enhanced General Purpose Input 4
9
Brown/Blue
General Purpose Input 5
10
Brown/Yellow
General Purpose Input 6
11
Orange
General Purpose Input 7
12
Yellow
General Purpose Input 8
13
Black
Signal Ground
14
Yellow
Fuel Flow Input 1
15
Red
+12 volts DC Auxiliary Power Output
16
Black
Signal Ground
17
Black
Signal Ground
18
White/Red
+5 volts DC Auxiliary Power Output
(Limited to 300 mA by internal self-resetting
fuse)
19
White/Black
Fuel Flow Input 2
20
Orange/Brown
General Purpose Input 9
21
Orange/Blue
General Purpose Input 10
22
Violet/Yellow
Enhanced General Purpose Input 2
23
Violet/Green
Enhanced General Purpose Input 3
24
Orange/Green
Amps+ Input
25
Orange/Violet
Amps- Input
26
Green/Red
Manifold Pressure Input
27
Open
RPM Signal to Rotax 912 iS Prop Controller
(optional)
28
Open
NOTE: Must be grounded to common
ground with Prop Controller
