Appendix E: Serial Data Output
SkyView HDX System Installation Manual - Revision E 27-7
Position
Width
Name
Pin
Description
42
3
Fuel Level R
(gal)
Varies
000 to 999 or XXX. Fuel level in 1/10
th
Gallons.
128 = 12.8 Gallons.
There must be a Level sensor named “RIGHT”
for this to work. See note 2.
45
3
Fuel
Remaining
(gal)
Fuel
Computer
000 to 999 or XXX. Fuel level in 1/10
th
Gallons.
This is derived from the fuel computer and is
based on the fuel on board added set by the
user and the decremented by fuel flow. See
note 2.
48
3
Volts 1
C37 P1
000 to 360 in 1/10
th
Volts. 284 = 28.4 volts. See
note 2.
51
3
Volts 2
C37 P2
000 to 360 in 1/10
th
Volts. 284 = 28.4 volts. See
note 2.
54
4
Amps
C37 P24/25
+/- then 000 to 999. 1/10
th
Amps. -083 = -
8.3A. See note 2.
58
5
Hobbs Time
Calculated
00000 to 99999. In 1/10 hours. 12345 = 1234.5
hours.
63
5
Tach Time
Calculated
00000 to 99999. In 1/10 hours. 12345 = 1234.5
hours.
68
4
Thermocouple
1 (deg C)
C25 P2/14
+/- then 000 to 999. In degrees C. See note 2.
72
4
Thermocouple
2 (deg C)
C25 P3/15
+/- then 000 to 999. In degrees C. See note 2.
76
4
Thermocouple
3 (deg C)
C25 P4/16
+/- then 000 to 999. In degrees C. See note 2.
80
4
Thermocouple
4 (deg C)
C25 P5/17
+/- then 000 to 999. In degrees C. See note 2.
84
4
Thermocouple
5 (deg C)
C25 P6/18
+/- then 000 to 999. In degrees C. See note 2.
88
4
Thermocouple
6 (deg C)
C25 P7/19
+/- then 000 to 999. In degrees C. See note 2.
92
4
Thermocouple
7 (deg C)
C25 P8/20
+/- then 000 to 999. In degrees C. See note 2.
96
4
Thermocouple
8 (deg C)
C25 P9/21
+/- then 000 to 999. In degrees C. See note 2.
100
4
Thermocouple
9 (deg C)
C25 P10/22
+/- then 000 to 999. In degrees C. See note 2.
104
4
Thermocouple
10 (deg C)
C25 P11/23
+/- then 000 to 999. In degrees C. See note 2.
108
4
Thermocouple
11 (deg C)
C25 P12/24
+/- then 000 to 999. In degrees C. See note 2.
112
4
Thermocouple
12 (deg C)
C25 P13/25
+/- then 000 to 999. In degrees C. See note 2.
116
4
Thermocouple
13 (deg C)
C37 P27/28
+/- then 000 to 999. In degrees C. See note 2.
120
4
Thermocouple
14 (deg C)
C37 P36/37
+/- then 000 to 999. In degrees C. See note 2.
124
6
GP Input 1
C37 P4
+/- then 0000 to 9999, then units. See notes.
Example: +1234C = 123.4 degrees C.
