106 Solution Ultima 844/862/880 Installation Manual
To exit the Installer's Programming Mode, enter command
960followed by the #button. Two
beeps will be heard and the system will return to the disarmed state. Refer to Installer’s Programming
Commands on page 107 for further information on commands that can be performed during access of
the Installer's Programming Mode.
When using the hand held programmer, any reference in this manual made to the button
should be considered as the *button and the button considered as the #button.
Programming With The Programming Key
The Programming Key (CC891) is a unique device that will allow you to store or copy programming
information from your control panel. Once the programming key has information stored in the
microprocessor, the programming key may be used to easily program other existing
Solution
Ultima 844/862/880
control panels with the same programming data, or be alternatively used for
back up purposes of existing information.
Connecting a programming key, which has been pre-programmed directly onto the control panel in
the disarmed state, will automatically initiate a data transfer from the programming key to the control
panel memory.
If you have a new programming key, you should first enter the Installer's Programming Mode and
program the system as required before connecting the programming key to the control panel.
To connect the programming key, locate the socket marked PROGRAMMING KEY found at the top
of the PCB (printed circuit board) next to the Auxiliary Module socket. Observe the triangular
markings on the printed circuit board and line them up with the markings on the programming key.
To copy the control panel's data into the programming key, access Installer’s Programming Mode
(e.g.:
1234 followed by the #button) and enter Installer’s Programming Command 962
followed by the
# button. Refer to Command 962 - Copy Control Panel Memory To Programming
Key on page 111 for further information.
To exit the Installer's Programming Mode, enter command
960followed by the #button. Two
beeps will be heard and the system will return to the disarmed state. Before removing the
programming key, wait two seconds for the activity LED to return to its normal state. The
programming key will now become your standard data pattern for future programming of your control
panels.
It should be noted that when entering the Installer's Programming Mode, inserting a programming key
and then changing any location will cause a simultaneous update of not only the programming keys
data, but also the control panel’s data. Therefore, you are not able to change data in the programming
key without the same location being changed in the control panel’s memory.
Connecting a Programming Key (CC891) to the control panel when the programming keys
memory is blank will corrupt the control panel's memory unless the Installer's Programming
Mode has been entered first. If this occurs, then the control panel will need to be returned to
Electronics Design and Manufacturing Pty Limited where a service fee will be charged to unlock
the control panel's memory.
ISSUE162.DOC Electronics Design and Manufacturing Pty Limited
