System Functions 71
4
Setting STAY Mode 2 Zones
This function allows the installer to select which zones are to be automatically isolated when the
system is armed in STAY Mode 2.
Every time the system is armed in STAY Mode 2, the zones selected using this function will be
automatically isolated.
To arm the system in STAY Mode 2, hold down the
0 button until two beeps are heard. Refer to
Hold Down Functions on page 93 or Arming The System In STAY Mode 2 on page 45 for more
information.
How To Set STAY Mode 2 Zones
1. Enter your followed by 4and the button.
Three beeps will be heard and the
STAY indicator will begin to flash.
2. * Enter the
that you wish to automatically isolate followed by the button.
The corresponding
ZONE indicator will begin to flash to display that you have selected that
zone to be automatically isolated every time you arm the system in STAY Mode 2.
If more than one zone is required to be automatically isolated in STAY Mode 2, repeat step 2
until all zones required have been selected.
3. Press the
button to exit this function.
Two beeps will be heard and the system will return to the disarmed state. The zones that were
selected to be automatically isolated in STAY Mode 2 and the
STAY indicator will extinguish.
+
4
+
+
+ +
* As each zone has been selected to be isolated, the corresponding ZONE indicator will begin
to flash. If a mistake has been made, press the zone number that was incorrectly entered
followed by the button. This zone is now no longer programmed to be isolated and
the ZONE indicator will extinguish.
This function will not operate on Solution Ultima 880 control panels that have been
partitioned.
Example
If you wish to select zones 2, 5 and 6 to be automatically isolated when arming in STAY Mode 2,
follow the sequence below.
1234
+
4
+
+
2
+ +
5
+ +
6
+ +
Electronics Design and Manufacturing Pty Limited ISSUE162.DOC
